VGS-350 Series

Manufacturer: CUI Inc.

Catalog

AC/DC CONVERTER 36V 349W

Part	Voltage - Isolation	Number of Outputs	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Voltage - Input [Max]	Voltage - Input [Min]	Type	Features	Approval Agency	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Current - Output 1	Standard Number	Power (Watts)	Mounting Type	Voltage - Output 1 [custom]	Efficiency	Voltage - Output 1
CUI Inc. VGS-350C-36	3000 V	1	1.18 in	4.53 in	115 mm	215 mm	30 mm	8.47 in	132 VAC 264 VAC 373 VDC	90 VAC 180 VAC 240 VDC	Enclosed	Adjustable Output Universal Input	CE cURus	-30 °C	70 °C	Household Appliances ITE (Commercial)	9.7 A	60335-1 62368-1	349 W	Chassis Mount	36 V	88 %
CUI Inc. VGS-350C-5-B	3000 V	1	1.18 in	4.53 in	115 mm	215 mm	30 mm	8.47 in	132 VAC 264 VAC 373 VDC	90 VAC 180 VAC 240 VDC	Conformal Coated Enclosed	Adjustable Output Universal Input	CE cURus	-30 °C	70 °C	Household Appliances ITE (Commercial)	60 A	60335-1 62368-1	300 W	Chassis Mount		84 %	5 V
CUI Inc. VGS-350C-5-A	3000 V	1	1.18 in	4.53 in	115 mm	215 mm	30 mm	8.47 in	132 VAC 264 VAC 373 VDC	90 VAC 180 VAC 240 VDC	Enclosed	Adjustable Output Universal Input	CE cURus	-30 °C	70 °C	Household Appliances ITE (Commercial)	60 A	60335-1 62368-1	300 W	Chassis Mount		84 %	5 V
CUI Inc. VGS-350C-15	3000 V	1	1.18 in	4.53 in	115 mm	215 mm	30 mm	8.47 in	132 VAC 264 VAC 373 VDC	90 VAC 180 VAC 240 VDC	Enclosed	Adjustable Output Universal Input	CE cURus	-30 °C	70 °C	Household Appliances ITE (Commercial)	23.2 A	60335-1 62368-1	348 W	Chassis Mount		87 %	15 V
CUI Inc. VGS-350C-48-A	3000 V	1	1.18 in	4.53 in	115 mm	215 mm	30 mm	8.47 in	132 VAC 264 VAC 373 VDC	90 VAC 180 VAC 240 VDC	Enclosed	Adjustable Output Universal Input	CE cURus	-30 °C	70 °C	Household Appliances ITE (Commercial)	7.3 A	60335-1 62368-1	350 W	Chassis Mount		89 %	48 V
CUI Inc. VGS-350C-48-B	3000 V	1	1.18 in	4.53 in	115 mm	215 mm	30 mm	8.47 in	132 VAC 264 VAC 373 VDC	90 VAC 180 VAC 240 VDC	Conformal Coated Enclosed	Adjustable Output Universal Input	CE cURus	-30 °C	70 °C	Household Appliances ITE (Commercial)	7.3 A	60335-1 62368-1	350 W	Chassis Mount		89 %	48 V
CUI Inc. VGS-350B-48	1.5 kV	1	1.18 in	4.53 in	115 mm	215 mm	30 mm	8.46 in	132 VAC 264 VAC	90 VAC 180 VAC	Enclosed	Adjustable Output	CB Scheme EN FCC IEC SIQ TUV UL	-20 °C	70 °C	ITE (Commercial)	7.3 A	55024 55032 Class B 60950-1 61000-3-2 61000-3-3	350 W	Chassis Mount		89 %	48 V
CUI Inc. VGS-350B-30	1.5 kV	1	1.18 in	4.53 in	115 mm	215 mm	30 mm	8.46 in	132 VAC 264 VAC	90 VAC 180 VAC	Enclosed	Adjustable Output	CB Scheme EN FCC IEC SIQ TUV UL	-20 °C	70 °C	ITE (Commercial)	11.6 A	55024 55032 Class B 60950-1 61000-3-2 61000-3-3	348 W	Chassis Mount		88 %	30 V
CUI Inc. VGS-350B-12	1.5 kV	1	1.18 in	4.53 in	115 mm	215 mm	30 mm	8.46 in	132 VAC 264 VAC	90 VAC 180 VAC	Enclosed	Adjustable Output	CB Scheme EN FCC IEC SIQ TUV UL	-20 °C	70 °C	ITE (Commercial)	29 A	55024 55032 Class B 60950-1 61000-3-2 61000-3-3	348 W	Chassis Mount		85 %	12 V
