FZ30 Series

Manufacturer: INFINEON

Catalog

IGBT MODULE

Part	IGBT Type	Power - Max [Max]	Mounting Type	Current - Collector Cutoff (Max) [Max]	Input	Supplier Device Package	Voltage - Collector Emitter Breakdown (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Current - Collector (Ic) (Max) [Max]	Vce(on) (Max) @ Vge, Ic	Configuration	Input Capacitance (Cies) @ Vce	NTC Thermistor	Package / Case
INFINEON FZ30R07W1E3B31ABOMA1	Trench Field Stop	150 W	Chassis Mount	50 µA	Standard	Module	650 V	-40 °C	150 °C	45 A	2 V	Single Switch	1.65 nF		Module
