ASPI-LR Series
Manufacturer: Abracon LLC
Beta
⌘K
POWER INDUCTORS - SMD IND 3.3UH 9.7A 14.9MOHMS
| Part | Current - Saturation (Isat) | DC Resistance (DCR) [Max] | Inductance | Type | Material - Core | Inductance Frequency - Test | Current Rating (Amps) | Package / Case | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Tolerance | Height - Seated (Max) | Height - Seated (Max) [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Shielding | Mounting Type | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Abracon LLC | 9.7 A | 14.9 mOhm | 3.3 µH | Molded | Metal Composite | 100 kHz | 10.5 A | Nonstandard | 0.323 in | 8.2 mm | 8.6 mm | 0.339 " | 20 % | 4 mm | 0.157 in | -55 C | 125 °C | Shielded | Surface Mount | ||
 Abracon LLC | 3.8 A | 55.1 mOhm | 10 µH | Molded | Metal Composite | 100 kHz | 5.3 A | Nonstandard | 0.323 in | 8.2 mm | 8.6 mm | 0.339 " | 30 % | -55 C | 125 °C | Shielded | Surface Mount | 0.118 " | 3 mm | ||
Abracon LLC | 16 A | 2.15 mOhm | 330 nH | Molded | Metal Composite | 100 kHz | 27.5 A | Nonstandard | 0.323 in | 8.2 mm | 8.6 mm | 0.339 " | 20 % | 4 mm | 0.157 in | -55 C | 125 °C | Shielded | Surface Mount | ||
 Abracon LLC | 6.7 A | 33.4 mOhm | 6.8 µH | Molded | Metal Composite | 100 kHz | 7 A | Nonstandard | 0.323 in | 8.2 mm | 8.6 mm | 0.339 " | 20 % | 4 mm | 0.157 in | -55 C | 125 °C | Shielded | Surface Mount | ||
Abracon LLC | 3.8 A | 85.3 mOhm | 15 µH | Molded | Metal Composite | 100 kHz | 4.3 A | Nonstandard | 0.323 in | 8.2 mm | 8.6 mm | 0.339 " | 20 % | -55 C | 125 °C | Shielded | Surface Mount | 0.118 " | 3 mm |
