PQMCE1 Series

Manufacturer: CUI Inc.

Catalog

DC DC CONVERTER 3.3V 825MW

Part	Type	Voltage - Output 1	Voltage - Input (Min) [Min]	Voltage - Isolation	Package / Case	Voltage - Input (Max) [Max]	Standard Number	Applications	Approval Agency	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Number of Outputs	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Current - Output (Max) [Max]	Power (Watts)	Efficiency
CUI Inc. PQMCE1-S5-S3-S	Isolated Module	3.3 V	4.75 V	1.5 kV	7-SIP Module 4 Leads	5.25 V	55024 55032	ITE (Commercial)	EN	0.24 "	0.4 "	19.7 mm	10.2 mm	0.77 in	6 mm	1	-40 °C	85 °C	Through Hole	250 mA	825 mW	67 %
CUI Inc. PQMCE1-S5-S12-S	Isolated Module	12 V	4.75 V	1.5 kV	7-SIP Module 4 Leads	5.25 V	55024 55032 Class A 62368-1	ITE (Commercial)	CB Scheme EN IEC UL	0.24 "	0.4 "	19.7 mm	10.2 mm	0.77 in	6 mm	1	-40 °C	85 °C	Through Hole	84 mA		72 %
CUI Inc. PQMCE1-S5-S9-S	Isolated Module	9 V	4.75 V	1.5 kV	7-SIP Module 4 Leads	5.25 V	55024 55032 Class A 62368-1	ITE (Commercial)	CB Scheme EN IEC UL	0.24 "	0.4 "	19.7 mm	10.2 mm	0.77 in	6 mm	1	-40 °C	85 °C	Through Hole	110 mA	0.99 W	71 %
CUI Inc. PQMCE1-S5-S15-S	Isolated Module	15 V	4.75 V	1.5 kV	7-SIP Module 4 Leads	5.25 V	55024 55032 Class A 62368-1	ITE (Commercial)	CB Scheme EN IEC UL	0.24 "	0.4 "	19.7 mm	10.2 mm	0.77 in	6 mm	1	-40 °C	85 °C	Through Hole	67 mA		73 %
CUI Inc. PQMCE1-S5-S5-S	Isolated Module	5 V	4.75 V	1.5 kV	7-SIP Module 4 Leads	5.25 V	55024 55032 Class A 62368-1	ITE (Commercial)	CB Scheme EN IEC UL	0.24 "	0.4 "	19.7 mm	10.2 mm	0.77 in	6 mm	1	-40 °C	85 °C	Through Hole	200 mA		70 %
CUI Inc. PQMCE1-S5-S24-S	Isolated Module	24 V	4.75 V	1.5 kV	7-SIP Module 4 Leads	5.25 V		ITE (Commercial)	CE cURus	0.24 "	0.4 "	19.7 mm	10.2 mm	0.77 in	6 mm	1	-40 °C	85 °C	Through Hole	41 mA	984 mW	73 %
