1571920 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

SWITCH TOGGLE SPDT 6A 125V

Part	Electrical Life	Actuator Material	Panel Cutout Dimensions [diameter]	Actuator Length [x]	Voltage Rating - AC	Illumination	Actuator Type	Current Rating (Amps)	Mounting Type	Voltage Rating - DC	Operating Temperature [Max]	Operating Temperature [Min]	Circuit	Switch Function	Termination Style	Features	Bushing Thread
TE Connectivity AMP Connectors 1571920-5	60000 Cycles	Copper Alloy Chrome Plated	6.4 mm	10.49 mm	125 V	Non-Illuminated	Standard Round	4 A 6 A	Panel Mount	28 V	80 °C	-20 ░C	SPDT	On-Off-On	Solder Lug	Epoxy Sealed Terminals	1/4-40
TE Connectivity AMP Connectors 1-1571920-0	60000 Cycles	Copper Alloy Chrome Plated	6.4 mm	10.49 mm	125 V	Non-Illuminated	Standard Round	4 A 6 A	Panel Mount	28 V	80 °C	-20 ░C	SPDT	Mom-Off-Mom	PC Pin	Epoxy Sealed Terminals	1/4-40
TE Connectivity AMP Connectors 2-1571920-7	60000 Cycles	Copper Alloy Chrome Plated	6.4 mm	10.49 mm	125 V	Non-Illuminated	Standard Round	4 A 6 A	Panel Mount	28 V	80 °C	-20 ░C	DPDT	On-Off-Mom	Solder Lug	Epoxy Sealed Terminals	1/4-40
TE Connectivity AMP Connectors 1571920-9	60000 Cycles	Copper Alloy Chrome Plated	6.4 mm	10.49 mm	125 V	Non-Illuminated	Standard Round	4 A 6 A	Panel Mount	28 V	80 °C	-20 ░C	SPDT	Mom-Off-Mom	Solder Lug	Epoxy Sealed Terminals	1/4-40
TE Connectivity AMP Connectors 3-1571920-7	60000 Cycles	Copper Alloy Chrome Plated	6.4 mm	10.49 mm	125 V	Non-Illuminated	Standard Round	4 A 6 A	Panel Mount	28 V	80 °C	-20 ░C	3PDT	On-Off-Mom	PC Pin	Epoxy Sealed Terminals	1/4-40
TE Connectivity AMP Connectors 1-1571920-7	60000 Cycles	Copper Alloy Chrome Plated	6.4 mm	10.49 mm	125 V	Non-Illuminated	Standard Round	4 A 6 A	Panel Mount	28 V	80 °C	-20 ░C	DPDT	On-Off-On	Solder Lug	Epoxy Sealed Terminals	1/4-40
TE Connectivity AMP Connectors 3-1571920-2	60000 Cycles	Copper Alloy Chrome Plated	6.4 mm	10.49 mm	125 V	Non-Illuminated	Standard Round	4 A 6 A	Panel Mount	28 V	80 °C	-20 ░C	3PDT	On-Off-On	Solder Lug	Epoxy Sealed Terminals	1/4-40
TE Connectivity AMP Connectors 1571920-7	60000 Cycles	Copper Alloy Chrome Plated	6.4 mm	10.49 mm	125 V	Non-Illuminated	Standard Round	4 A 6 A	Panel Mount	28 V	80 °C	-20 ░C	SPDT	On-Mom	Solder Lug	Epoxy Sealed Terminals	1/4-40
TE Connectivity AMP Connectors 4-1571920-0	60000 Cycles	Copper Alloy Chrome Plated	6.4 mm	10.49 mm	125 V	Non-Illuminated	Standard Round	4 A 6 A	Panel Mount	28 V	80 °C	-20 ░C	4PDT	On-Off-On	Solder Lug	Epoxy Sealed Terminals	1/4-40
TE Connectivity AMP Connectors 3-1571920-8	80000 Cycles	Copper Alloy Chrome Plated	6.4 mm	10.49 mm	125 V	Non-Illuminated	Standard Round	4 A 6 A	Panel Mount	28 V	80 °C	-20 ░C	4PDT	On-On	Solder Lug	Epoxy Sealed Terminals	1/4-40
