837-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 14POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Card Type | Termination | Contact Finish | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Number of Positions | Contact Type | Mounting Type | Gender | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Color | Read Out | Contact Material | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Solder | Gold | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | 14 | Cantilever | Through Hole | Female | 7 | 125 °C | -40 C | Green | Dual | Copper Alloy | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 3.96 mm | 0.156 in | 14 | Cantilever | Through Hole | Female | 14 | 125 °C | -40 C | Green | Single | Copper Alloy | 1 | 1 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Solder | Gold | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | 14 | Cantilever | Board Edge Straddle Mount | Female | 7 | 125 °C | -40 C | Green | Dual | Copper Alloy | Card Extender | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Wire Wrap | Gold | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | 14 | Cantilever | Through Hole | Female | 7 | 125 °C | -40 C | Green | Dual | Copper Alloy | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Solder | Gold | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 14 | Cantilever | Through Hole | Female | 7 | 125 °C | -40 C | Green | Dual | Copper Alloy | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | 14 | Cantilever | Through Hole | Female | 14 | 125 °C | -40 C | Green | Single | Copper Alloy | 1 | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | 14 | Cantilever | Through Hole | Female | 14 | 125 °C | -40 C | Green | Single | Copper Alloy | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Solder Eyelet(s) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | 14 | Cantilever | Through Hole | Female | 14 | 125 °C | -40 C | Green | Single | Copper Alloy | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | 14 | Cantilever | Right Angle Through Hole | Female | 14 | 125 °C | -40 C | Green | Single | Copper Alloy | 1 | 1 | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Solder | Gold | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | 14 | Cantilever | Through Hole | Female | 7 | 125 °C | -40 C | Green | Dual | Copper Alloy |
