TLE7240 Series
Manufacturer: Infineon Technologies
Beta
⌘K
IC PWR DRIVER N-CHANNEL 1:2
| Part | Output Configuration | Package / Case | Package / Case [custom] | Ratio - Input:Output [custom] | Current - Output (Max) [Max] | Supplier Device Package | Mounting Type | Rds On (Typ) | Fault Protection | Switch Type | Operating Temperature [Max] | Operating Temperature [Min] | Interface | Output Type | Voltage - Load | Voltage - Supply (Vcc/Vdd) [Max] | Voltage - Supply (Vcc/Vdd) [Min] | Number of Outputs | Features | Input Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Infineon Technologies | Low Side | 24-SSOP | 0.154 " 3.9 mm | 1:2 | 210 mA | PG-SSOP-24-7 | Surface Mount | 1.5 Ohm | Open Load Detect Over Temperature | Relay Solenoid Driver | 150 °C | -40 °C | SPI | N-Channel | 41 V | 5.5 V | 3 V | 8 | ||
 Infineon Technologies | Low Side | 24-SSOP | 0.154 " 3.9 mm | 1:2 | 210 mA | PG-SSOP-24-7 | Surface Mount | 1.5 Ohm | Open Load Detect Over Temperature Short Circuit | Relay Solenoid Driver | 150 °C | -40 °C | SPI | N-Channel | 41 V | 5.5 V | 3 V | 8 | Load Discharge | Non-Inverting |
