3220-24 Series
Manufacturer: CNC Tech
Beta
⌘K
CONN HEADER R/A 24POS 1.27MM
| Part | Style | Features | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Contact Material | Mounting Type | Insulation Height | Insulation Height | Number of Rows [custom] | Pitch - Mating | Pitch - Mating | Number of Positions | Fastening Type | Shrouding | Contact Length - Post | Contact Length - Post | Voltage Rating | Contact Type | Row Spacing - Mating | Row Spacing - Mating | Connector Type | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Number of Positions Loaded | Contact Shape | Insulation Material | Material Flammability Rating | Insulation Height [z] | Insulation Height [z] | Contact Finish - Mating | Insulation Color | Contact Finish Thickness - Mating | Contact Finish Thickness - Post | Contact Finish - Post |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CNC Tech | Board to Cable/Wire | Keying Slot | -40 C | 105 ░C | Solder | Brass | Right Angle Through Hole | 0.201 in | 5.1 mm | 2 | 1.27 mm | 0.05 in | 24 | Push-Pull | Shrouded - 4 Wall | 0.083 in | 2.11 mm | 50 VAC | Male Pin | 0.05 in | 1.27 mm | Header | 2.03 µm | 80 µin | All | Square | Nylon 6T Polyamide (PA6T) | UL94 V-0 | |||||||
 CNC Tech | Board to Cable/Wire | Keying Slot | -40 C | 105 ░C | Solder | Brass | Through Hole | 2 | 1.27 mm | 0.05 in | 24 | Push-Pull | Shrouded - 4 Wall | 0.083 in | 2.11 mm | 50 VAC | Male Pin | 0.05 in | 1.27 mm | Header | All | Square | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 0.213 " | 5.4 mm | Gold | Black | Flash | ||||||
 CNC Tech | Board to Cable/Wire | Keying Slot | -40 C | 105 ░C | Solder | Brass | Surface Mount | 2 | 1.27 mm | 0.05 in | 24 | Push-Pull | Shrouded - 4 Wall | 50 VAC | Male Pin | 0.05 in | 1.27 mm | Header | All | Square | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 0.213 " | 5.4 mm | Gold | Black | Flash | Flash | Gold | ||||||
CNC Tech | Board to Cable/Wire | Keying Slot | -40 C | 105 ░C | Solder | Brass | Surface Mount | 2 | 1.27 mm | 0.05 in | 24 | Push-Pull | Shrouded - 4 Wall | 50 VAC | Male Pin | 0.05 in | 1.27 mm | Header | 2.03 µm | 80 µin | All | Square | Nylon 6T Polyamide (PA6T) | UL94 V-0 | 0.213 " | 5.4 mm | Black | ||||||||
 CNC Tech | Board to Cable/Wire | Keying Slot | -40 C | 105 ░C | Solder | Brass | Right Angle Through Hole | 0.201 in | 5.1 mm | 2 | 1.27 mm | 0.05 in | 24 | Push-Pull | Shrouded - 4 Wall | 0.083 in | 2.11 mm | 50 VAC | Male Pin | 0.05 in | 1.27 mm | Header | All | Square | Nylon 9T Polyamide (PA9T) | UL94 V-0 | Gold | Black | Flash | ||||||
CNC Tech | Board to Cable/Wire | Keying Slot | -40 C | 105 ░C | Solder | Brass | Through Hole | 2 | 1.27 mm | 0.05 in | 24 | Push-Pull | Shrouded - 4 Wall | 0.083 in | 2.11 mm | 50 VAC | Male Pin | 0.05 in | 1.27 mm | Header | 2.03 µm | 80 µin | All | Square | Nylon 6T Polyamide (PA6T) | UL94 V-0 | 0.213 " | 5.4 mm |
