SCHRACK V23148 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RELAY GEN PURPOSE SPDT 7A 6V
| Part | Coil Resistance | Contact Rating (Current) | Must Release Voltage | Relay Type | Load - Max Switching | Coil Type | Termination Style | Contact Material | Switching Voltage [Max] | Coil Current | Operate Time | Must Operate Voltage | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Form | Release Time | Coil Voltage | Load - Max Switching [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 80 Ohms | 7 A | 0.6 VDC | General Purpose | 2800 VA | Non Latching | PC Pin | Silver Nickel (AgNi) | 400 VAC | 0.075 A | 5 ms | 4.2 VDC | Through Hole | -25 °C | 70 °C | SPDT (1 Form C) | 3 ms | ||
 TE Connectivity AMP Connectors | 7 A | 1.2 VDC | General Purpose | 2800 VA | Non Latching | PC Pin | Silver Nickel (AgNi) | 400 VAC | 0.0375 A | 5 ms | 8.4 VDC | Through Hole | -25 °C | 70 °C | SPST-NO (1 Form A) | 3 ms | 12 VDC | ||
 TE Connectivity AMP Connectors | 1.78 kOhms | 5 A | 2.4 VDC | General Purpose | Non Latching | PC Pin | Silver Nickel (AgNi) | 400 VAC | 16.7 mA | 7 ms | 17.5 VDC | Through Hole | -25 °C | 70 °C | SPST-NO (1 Form A) | 3 ms | 24 VDC | 2000 VA | |
TE Connectivity AMP Connectors | 110 Ohms | 5 A | 0.6 VDC | General Purpose | Non Latching | PC Pin | Silver Nickel (AgNi) | 400 VAC | 16.7 mA | 7 ms | 4.4 VDC | Through Hole | -25 °C | 70 °C | SPST-NO (1 Form A) | 3 ms | 2000 VA | ||
 TE Connectivity AMP Connectors | 1.78 kOhms | 5 A | 2.4 VDC | General Purpose | Non Latching | PC Pin | Silver Nickel (AgNi) | 400 VAC | 16.7 mA | 7 ms | 17.5 VDC | Through Hole | -25 °C | 70 °C | SPDT (1 Form C) | 3 ms | 24 VDC | 2000 VA | |
 TE Connectivity AMP Connectors | |||||||||||||||||||
 TE Connectivity AMP Connectors | |||||||||||||||||||
TE Connectivity AMP Connectors | 440 Ohms | 5 A | 1.2 VDC | General Purpose | Non Latching | PC Pin | Silver Nickel (AgNi) | 400 VAC | 16.7 mA | 7 ms | 8.8 VDC | Through Hole | -25 °C | 70 °C | SPDT (1 Form C) | 3 ms | 12 VDC | 2000 VA | |
 TE Connectivity AMP Connectors | 7 A | 1.2 VDC | General Purpose | 2800 VA | Latching Single Coil | PC Pin | Silver Nickel (AgNi) | 400 VAC | 0.0375 A | 5 ms | 8.4 VDC | Through Hole | -25 °C | 70 °C | SPST-NO (1 Form A) | 3 ms | 12 VDC | ||
TE Connectivity AMP Connectors | 1.78 kOhms | 5 A | 2.4 VDC | General Purpose | Non Latching | PC Pin | Silver Nickel (AgNi) | 400 VAC | 16.7 mA | 7 ms | 17.5 VDC | Through Hole | -25 °C | 70 °C | SPDT (1 Form C) | 3 ms | 24 VDC | 2000 VA |
