TJ08 Series

Catalog

TERM BLOCK PLUG 8POS STR 5MM

Part	Color	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Material Flammability Rating	Type	Pitch [x]	Pitch [x]	Current - IEC	Termination Style	Number of Positions	Contact Material	Number of Levels	Mounting Type	Contact Mating Finish	Torque - Screw	Torque - Screw	Current - UL	Operating Temperature [Min]	Operating Temperature [Max]	Positions Per Level	Wire Gauge or Range - mm² [Min]	Wire Gauge or Range - mm² [Max]	Wire Strip Length [Min]	Wire Strip Length [Max]	Insulation Height	Insulation Height	Screw Size	Housing Material	Voltage - UL	Voltage - IEC	Features	Wire Gauge or Range - mm˛ [Min]	Wire Gauge or Range - mm˛ [Max]	Wire Gauge or Range - mm˛
Amphenol Anytek TJ0871800000G	Gray	24 AWG	12 AWG	UL94 V-0	Plug Female Sockets	5 mm	0.197 in	20 A	Screw	8	Copper	1	Free Hanging (In-Line)	Tin	0.56 Nm	5 Lb-In	20 A	-40 °C	115 °C	8	0.34 mm²	2.5 mm²	7 mm	8 mm	0.594 in	15.09 mm	M3	Thermoplastic	300 V	300 V
Amphenol Anytek TJ0851560000G	Green	24 AWG	12 AWG	UL94 V-0	Plug Female Sockets	5.08 mm	0.2 in		Screw - Rising Cage Clamp	8	Copper Alloy	1	Free Hanging (In-Line)	Tin	0.56 Nm	5 Lb-In	12 A	-40 °C	115 °C	8	1 mm²	2.5 mm²	7 mm	8 mm	0.594 in	15.09 mm	M3	Thermoplastic Resin	300 V
Amphenol Anytek TJ0851070000G	Black	24 AWG	12 AWG	UL94 V-0	Plug Female Sockets	5.08 mm	0.2 in		Screw	8	Copper	1	Free Hanging (In-Line)	Tin	0.56 Nm	5 Lb-In	20 A	-40 °C	115 °C	8			7 mm	8 mm	0.594 in	15.09 mm	M3	Thermoplastic	300 V		Mating Flange Retention Latches (Non-Wire Side)
Amphenol Anytek TJ0851530000G	Green	24 AWG	12 AWG	UL94 V-0	Plug Female Sockets	5.08 mm	0.2 in		Screw - Rising Cage Clamp	8	Copper Alloy	1	Free Hanging (In-Line)	Tin	0.56 Nm	5 Lb-In	12 A	-40 °C	115 °C	8	1 mm²	2.5 mm²	7 mm	8 mm	0.594 in	15.09 mm	M3	Thermoplastic Resin	300 V
Amphenol Anytek TJ0871070000G	Black	24 AWG	12 AWG	UL94 V-0	Plug Female Sockets	5 mm	0.197 in		Screw	8	Copper	1	Free Hanging (In-Line)	Tin	0.56 Nm	5 Lb-In	20 A	-40 °C	115 °C	8			7 mm	8 mm	0.594 in	15.09 mm	M3	Thermoplastic	300 V		Mating Flange Retention Latches (Non-Wire Side)
Amphenol Anytek TJ0871500000G	Green	24 AWG	12 AWG	UL94 V-0	Plug Female Sockets	5 mm	0.197 in		Screw - Rising Cage Clamp	8	Copper Alloy	1	Free Hanging (In-Line)	Tin	0.56 Nm	5 Lb-In	12 A	-40 °C	115 °C	8			7 mm	8 mm	0.594 in	15.09 mm	M3	Thermoplastic Resin	300 V			1 mm˛	2.5 mm˛
Amphenol Anytek TJ0831830000G	Gray	28 AWG	16 AWG	UL94 V-0	Plug Female Sockets	3.81 mm	0.15 in	10.5 A	Screw	8	Phosphor Bronze	1	Free Hanging (In-Line)	Tin			10 A	-40 °C	115 °C	8			6 mm	7 mm	0.437 in	11.1 mm	M2	Thermoplastic	300 V	300 V				1.5 mm˛
Amphenol Anytek TJ0851040000G	Black	24 AWG	12 AWG	UL94 V-0	Plug Female Sockets	5.08 mm	0.2 in	20 A	Screw	8	Copper	1	Free Hanging (In-Line)	Tin	0.56 Nm	5 Lb-In	20 A	-40 °C	115 °C	8	0.34 mm²	2.5 mm²	7 mm	8 mm			M3	Thermoplastic	300 V	300 V	Retention Latches (Non-Wire Side) Strain Relief
Amphenol Anytek TJ0851840000G	Gray	24 AWG	12 AWG	UL94 V-0	Plug Female Sockets	5.08 mm	0.2 in	20 A	Screw	8	Copper	1	Free Hanging (In-Line)	Tin	0.56 Nm	5 Lb-In	20 A	-40 °C	115 °C	8	0.34 mm²	2.5 mm²	7 mm	8 mm			M3	Thermoplastic	300 V	300 V	Retention Latches (Non-Wire Side) Strain Relief
Amphenol Anytek TJ0831820000G	Gray	28 AWG	16 AWG	UL94 V-0	Plug Female Sockets	3.81 mm	0.15 in	10.5 A	Screw	8	Phosphor Bronze	1	Free Hanging (In-Line)	Tin			10 A	-40 °C	115 °C	8			6 mm	7 mm	0.437 in	11.1 mm	M2	Thermoplastic	300 V	300 V	Mating Flange			1.5 mm˛
