G3VM-61 Series

Manufacturer: Omron Electronics Inc-EMC Div

Catalog

RELAY SSR 6.2MA 6V DC-IN 0.4A 60V AC/DC-OUT 4-PIN S-VSON T/R

Part	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Termination Style	Mounting Type	On-State Resistance (Max) [Max]	Voltage - Input	Voltage - Load [Max]	Load Current	Output Type	Supplier Device Package	Package / Case	Package / Case	Package / Case [custom]	Package / Case
Omron Electronics Inc-EMC Div G3VM-61QVH(TR05)	85 °C	-40 °C	4-SMD (0.079" 2.00mm)	SMD (SMT) Tab	Surface Mount	1.5 Ohms	1.5 V	60 V	400 mA	AC DC
Omron Electronics Inc-EMC Div G3VM-61AR1	85 °C	-40 °C	4-DIP (0.300" 7.62mm)	PC Pin	Through Hole	100 mOhms	1.64 VDC	60 V	3 A	AC DC	4-DIP
Omron Electronics Inc-EMC Div G3VM-61FR1(TR05)	85 °C	-40 °C	8-SMD	Gull Wing	Surface Mount	50 mOhms	1.64 VDC	60 V	5 A	AC DC	8-SMD	7.62 mm	0.3 in
Omron Electronics Inc-EMC Div G3VM-61UR(TR05)	85 °C	-40 °C	4-SMD	SMD (SMT) Tab	Surface Mount	1.5 Ohms		60 V	400 mA	AC DC	4-VSON			0.096 in 2.45 mm
Omron Electronics Inc-EMC Div G3VM-61G1(TR)	85 °C	-40 °C	4-SOP	Gull Wing	Surface Mount	2 Ohm	1.15 VDC	60 V	400 mA	AC DC	4-SOP	4.4 mm	0.173 in
Omron Electronics Inc-EMC Div G3VM-61UR1(TR05)	85 °C	-40 °C	4-SMD	SMD (SMT) Tab	Surface Mount	15 Ohm		60 V	120 mA	AC DC	4-VSON			0.096 in 2.45 mm
Omron Electronics Inc-EMC Div G3VM-61HR1	85 °C	-40 °C	6-SOP	Gull Wing	Surface Mount	60 mOhms	1.33 VDC	60 V	3.3 A	AC DC	6-SOP				0.173 in 4.4 mm
Omron Electronics Inc-EMC Div G3VM-61QR2(TR05)	85 °C	-40 °C	4-SMD (0.079" 2.00mm)	SMD (SMT) Tab	Surface Mount	300 mOhm		60 V	1 A	AC DC	S-VSON4
Omron Electronics Inc-EMC Div G3VM-61PR(TR)	85 °C	-40 °C	4-SMD	SMD (SMT) Tab	Surface Mount	1.5 Ohms	1.15 VDC	60 V	400 mA	AC DC	4-USOP
Omron Electronics Inc-EMC Div G3VM-61VY	85 °C	-40 °C	4-SOP	Gull Wing	Surface Mount	50 Ohm	1.15 VDC	60 V	70 mA	AC DC	4-SOP	4.4 mm	0.173 in
