HIGH-DENSITY Screw Lock Series
Manufacturer: ODU
Beta
⌘K
CIRCULAR METRIC CONNECTORS HD PM RECPT W SL, SZ 1, IP6K8 / IP6K9K, 17 CONTACTS, D (GREEN) KEY
| Part | Shell Finish | Connector Type | Contact Finish - Mating | Fastening Type | Termination | Mounting Type | Insert Material | Mounting Feature | Applications | Color | Contact Material | Shell Size - Insert | Orientation | Operating Temperature [Min] | Operating Temperature [Max] | Ingress Protection | Shell Material | Primary Material | Shell Size - Insert [custom] | Cable Opening [Max] | Cable Opening [Min] | Number of Positions | Features | Current Rating (Amps) | Number of Positions [custom] | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Gold | Threaded | Solder | Panel Mount | Polyetheretherketone (PEEK) | Bulkhead - Front Side Nut | Industrial Medical Military | Black Silver | Copper Alloy | 1 | D | -51 °C | 125 °C | IP68 IP69K | Brass | Metal | |||||||||
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Gold | Threaded | Free Hanging (In-Line) | Polyetheretherketone (PEEK) | Industrial Medical Military | Black Silver | Copper Alloy | 1 | C | -51 °C | 125 °C | IP68 IP69K | Brass | Metal | |||||||||||
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Gold | Threaded | Free Hanging (In-Line) | Polyetheretherketone (PEEK) | Industrial Medical Military | Black Silver | Copper Alloy | C | -51 °C | 125 °C | IP68 IP69K | Brass | Metal | 0 | 0.276 " 7 mm | 0.126 in 3.2 mm | 16 | ||||||||
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Gold | Threaded | Solder | Panel Mount | Polyetheretherketone (PEEK) | Bulkhead - Front Side Nut | Industrial Medical Military | Black Silver | Copper Alloy | 1 | C | -51 °C | 125 °C | IP68 IP69K | Brass | Metal | |||||||||
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Gold | Threaded | Panel Mount | Polyetheretherketone (PEEK) | Bulkhead - Front Side Nut | Industrial Medical Military | Black Silver | Copper Alloy | D | -51 °C | 125 °C | IP68 IP69K | Brass | Metal | 0 | 0.197 in 5 mm | 0.126 in 3.2 mm | 4 | Board Guide | ||||||
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Gold | Threaded | Panel Mount Through Hole | Polyetheretherketone (PEEK) | Bulkhead - Front Side Nut | Industrial Medical Military | Black Silver | Copper Alloy | B | -51 °C | 125 °C | IP68 IP69K | Brass | Metal | 0 | 0.276 " 7 mm | 0.126 in 3.2 mm | Board Guide | 1 A 5 A | 2 | 10 | ||||
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Gold | Threaded | Panel Mount | Polyetheretherketone (PEEK) | Bulkhead - Front Side Nut | Industrial Medical Military | Black Silver | Copper Alloy | 1 | D | -51 °C | 125 °C | IP68 IP69K | Brass | Metal | 0.335 in 8.5 mm | 0.126 in 3.2 mm | 27 | |||||||
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Gold | Threaded | Solder | Panel Mount Through Hole | Polyetheretherketone (PEEK) | Bulkhead - Front Side Nut | Industrial Medical Military | Black Silver | Copper Alloy | B | -51 °C | 125 °C | IP68 IP69K | Brass | Metal | 0 | 0.276 " 7 mm | 0.126 in 3.2 mm | 8 | Board Guide | |||||
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Gold | Threaded | Free Hanging (In-Line) | Polyetheretherketone (PEEK) | Industrial Medical Military | Black Silver | Copper Alloy | B | -51 °C | 125 °C | IP68 IP69K | Brass | Metal | 0 | 12 | 1 A 5 A | |||||||||
Ruthenium over Electroless Nickel | Receptacle Female Sockets | Gold | Threaded | Panel Mount | Polyetheretherketone (PEEK) | Bulkhead - Front Side Nut | Industrial Medical Military | Black Silver | Copper Alloy | C | -51 °C | 125 °C | IP68 IP69K | Brass | Metal | 0 | 0.197 in 5 mm | 0.126 in 3.2 mm | 4 | Board Guide |
