8Y Series

Catalog

2.0X1.6 SEAM SEAL MHZ QUARTZ XTAL -4PAD / CERAMIC, +/-30PPM @25C, +/-30PPM (-20 TO 70C), 6PF

Part	Type	Load Capacitance	Height - Seated (Max) [Max]	Height - Seated (Max)	Operating Mode	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Mounting Type	Frequency Tolerance	Frequency Stability	Package / Case	ESR (Equivalent Series Resistance)	Frequency	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package [y]	Supplier Device Package [x]	Supplier Device Package [custom]	Height - Seated (Max) [Max]
TXC CORPORATION 8Y-30.000MAAB-T	MHz Crystal	8.5 pF	0.02 in	0.5 mm	Fundamental	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	30 ppm	30 ppm	4-SMD No Lead	80 Ohm	30 MHz	-20 ░C	70 °C	1.6	2	4-SMD
TXC CORPORATION 8Y50070001	MHz Crystal	8 pF	0.02 in	0.5 mm	Fundamental	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	10 ppm	10 ppm	4-SMD No Lead	80 Ohm	50 MHz	-20 ░C	70 °C	1.6	2	4-SMD
TXC CORPORATION 8Y-30.000MAHV-T	MHz Crystal	8 pF	0.02 in	0.5 mm	Fundamental	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	30 ppm	30 ppm	4-SMD No Lead	100 Ohms	30 MHz	-40 C	85 °C	1.6	2	4-SMD
TXC CORPORATION 8Y27100002	MHz Crystal	12 pF	0.02 in	0.5 mm	Fundamental	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	30 ppm	30 ppm	4-SMD No Lead	100 Ohms	27.12 MHz	-20 ░C	70 °C	1.6	2	4-SMD
TXC CORPORATION 8Y-37.400MAHQ-T	MHz Crystal	10 pF	0.02 in	0.5 mm	Fundamental	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	30 ppm	30 ppm	4-SMD No Lead	80 Ohm	37.4 MHz	-40 C	85 °C	1.6	2	4-SMD
TXC CORPORATION 8Y-38.400MDIV-T	MHz Crystal	8 pF	0.02 in	0.5 mm	Fundamental	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	20 ppm	20 ppm	4-SMD No Lead	80 Ohm	38.4 MHz	-40 C	85 °C	1.6	2	4-SMD
TXC CORPORATION 8Y-24.000MAAJ-T	MHz Crystal	18 pF	0.02 in 0.022 in	0.5 mm	Fundamental	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	30 ppm	30 ppm	4-SMD No Lead	100 Ohms	24 MHz	-20 ░C	70 °C	1.6	2	4-SMD	0.55 mm
TXC CORPORATION 8Y-40.000MEEE-T	MHz Crystal	12 pF	0.02 in	0.5 mm	Fundamental	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	10 ppm	10 ppm	4-SMD No Lead	80 Ohm	40 MHz	-20 ░C	70 °C	1.6	2	4-SMD
TXC CORPORATION 8Y-32.000MAHV-T	MHz Crystal	8 pF	0.02 in 0.022 in	0.5 mm	Fundamental	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	30 ppm	30 ppm	4-SMD No Lead	80 Ohm	32 MHz	-40 C	85 °C	1.6	2	4-SMD	0.55 mm
TXC CORPORATION 8Y-20.000MEEV-T	MHz Crystal	8 pF	0.02 in	0.5 mm	Fundamental	1.6 mm	0.079 in	0.063 "	2 mm	Surface Mount	10 ppm	10 ppm	4-SMD No Lead	100 Ohms	20 MHz	-20 ░C	70 °C	1.6	2	4-SMD
