Specialty Fuses 80A 690V 00TN/80 GR
Specialty Fuses 80A 690V 00TN/80 GR
| Part | Package / Case | Breaking Capacity @ Rated Voltage | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Voltage Rating - AC | Current Rating (Amps) | Mounting Type | Approval Agency | Applications | Melting I²t |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Eaton - Electronics Division | Rectangular Blade | 200 kA | 2.008 " | 1.181 in | 2.126 " | 30 mm | 51 mm | 54 mm | 700 VAC | 80 A | Bolt Mount | CE CSA UR | Electrical Industrial | |
 Eaton - Electronics Division | Rectangular Blade | 100 kA | 2.598 " | 2.087 " | 3.15 " | 53 mm | 66 mm | 80 mm | 1.3 kVAC | 315 A | Bolt Mount | CSA UR | Electrical Industrial | |
 Eaton - Electronics Division | Rectangular Blade | 100 kA | 2.953 " | 2.402 " | 3.15 " | 61 mm | 75 mm | 80 mm | 1.3 kVAC | Bolt Mount | CSA UR | Electrical Industrial | 34000 | |
Eaton - Electronics Division | Rectangular Blade | 100 kA | 2.953 " | 2.402 " | 3.15 " | 61 mm | 75 mm | 80 mm | 1.3 kVAC | 315 A | Bolt Mount | CSA UR | Electrical Industrial | 13000 |
