0678D Series
Manufacturer: Bel Fuse Inc.
Beta
⌘K
FUSE BRD MNT 630MA 350VAC 250VDC
| Part | Fuse Type | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Melting I²t | Voltage Rating - AC | Mounting Type | Response Time | Breaking Capacity @ Rated Voltage | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Voltage Rating - DC | Current Rating (Amps) | DC Cold Resistance | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | Board Mount (Cartridge Style Excluded) | -55 C | 125 °C | 2-SMD Square End Block | 0.06 | 350 V | Surface Mount | Fast Blow | 100 A | 0.12 in | 9.8 mm | 3.05 mm | 3.05 mm | 0.12 " | 0.386 " | 250 V | 0.63 A | ||
 Bel Fuse Inc. | Board Mount (Cartridge Style Excluded) | -55 C | 125 °C | 2-SMD Square End Block | 0.5 I²t | 350 V | Surface Mount | Fast Blow | 2 kA 100 A | 0.12 in | 9.8 mm | 3.05 mm | 3.05 mm | 0.12 " | 0.386 " | 125 VDC | 1.6 A | 0.08 Ohms | AEC-Q200 cURus |
Bel Fuse Inc. | Board Mount (Cartridge Style Excluded) | -55 C | 125 °C | 2-SMD Square End Block | 0.9 | 350 V | Surface Mount | Fast Blow | 2 kA 100 A | 0.12 in | 9.8 mm | 3.05 mm | 3.05 mm | 0.12 " | 0.386 " | 125 VDC | 2 A | ||
Bel Fuse Inc. | Board Mount (Cartridge Style Excluded) | -55 C | 125 °C | 2-SMD Square End Block | 0.03 I²t | 350 V | Surface Mount | Fast Blow | 100 A | 0.12 in | 9.8 mm | 3.05 mm | 3.05 mm | 0.12 " | 0.386 " | 250 V | 0.5 A | 0.66 Ohms | AEC-Q200 cURus |
Bel Fuse Inc. | Board Mount (Cartridge Style Excluded) | -55 C | 125 °C | 2-SMD Square End Block | 7.5 | 350 V | Surface Mount | Fast Blow | 2 kA 100 A | 0.12 in | 9.8 mm | 3.05 mm | 3.05 mm | 0.12 " | 0.386 " | 125 VDC | 4 A |
