BD62321HFP Series

H-bridge Drivers High current series

Catalog

H-bridge Drivers High current series

Part	Function	Current - Output	Interface	Mounting Type	Technology	Motor Type - AC, DC	Voltage - Load [Min]	Voltage - Load [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Voltage - Supply [Min]	Voltage - Supply [Max]	Applications	Output Configuration	Supplier Device Package
Rohm Semiconductor BD62321HFP-TR	Driver - Fully Integrated Control and Power Stage	3 A	On/Off	Surface Mount	Power MOSFET	Brushed DC	6 V	32 V	150 °C	-40 °C	D2PAK (7 Leads + Tab) TO-263-8 TO-263CA	6 V	32 VDC	Media Player	Half Bridge (2)	HRP7

Catalog

H-bridge Drivers High current series

Description

BD62321HFP is full bridge driver for brush motor applications. This IC can operate at a wide range of power-supply voltages (from 6V to 32V), supporting output currents of up to 3A. MOS transistors in the output stage allow for PWM signal control. The replacement is also easy because of the pin compatible with BD623XHFP series.
