TCM Series
Manufacturer: OptiFuse
Beta
⌘K
FUSE BRD MT 2.5A 125VAC/VDC 2410
| Part | Breaking Capacity @ Rated Voltage | Response Time | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating - DC | DC Cold Resistance | Mounting Type | Package / Case | Approval Agency | Melting I²t | Fuse Type | Current Rating (Amps) | Voltage Rating - AC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 OptiFuse | 50 A | Slow Blow | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | -55 C | 125 °C | 125 VDC | 40 mOhms | Surface Mount | 2410 (6125 Metric) | UL | 16.55 I²t | Board Mount (Cartridge Style Excluded) | 2.5 A | 125 V |
OptiFuse | 50 A | Slow Blow | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | -55 C | 125 °C | 125 VDC | Surface Mount | 2410 (6125 Metric) | UL | Board Mount (Cartridge Style Excluded) | 1.25 A | 125 V | ||
OptiFuse | 50 A | Slow Blow | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | -55 C | 125 °C | 125 VDC | 67 mOhms | Surface Mount | 2410 (6125 Metric) | UL | 3.835 | Board Mount (Cartridge Style Excluded) | 1.5 A | 125 V |
OptiFuse | 50 A | Slow Blow | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | -55 C | 125 °C | 125 VDC | 0.021 Ohms | Surface Mount | 2410 (6125 Metric) | UL | 54.8 | Board Mount (Cartridge Style Excluded) | 5 A | 125 V |
OptiFuse | 50 A | Slow Blow | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | -55 C | 125 °C | 125 VDC | 33 mOhms | Surface Mount | 2410 (6125 Metric) | UL | 22.54 | Board Mount (Cartridge Style Excluded) | 3 A | 125 V |
