AMPMODU 50/50 Grid Series
Manufacturer: TE Connectivity AMP Connectors
Catalog
100 50/50 GRID CABLE RECPT ROHS COMPLIANT: NO
...
| Part | Pitch | Pitch | Wire Gauge | Number of Positions | Number of Rows [custom] | Wire Type | Mounting Type | Features | Color | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Row Spacing | Row Spacing | Contact Finish | Connector Type | Cable Termination | Applications | Contact Finish Thickness - Post | Mated Stacking Heights | Current Rating (Amps) | Shrouding | Contact Finish - Post | Operating Temperature [Max] | Operating Temperature [Min] | Contact Shape | Insulation Color | Row Spacing - Mating | Row Spacing - Mating | Insulation Material | Contact Material | Contact Finish - Mating | Fastening Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Material Flammability Rating | Insulation Height | Insulation Height | Termination | Pitch - Mating | Pitch - Mating | Contact Length - Mating | Contact Length - Mating | Number of Positions Loaded | Insulation Height [z] | Insulation Height [z] | For Use With/Related Products | Accessory Type | Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 0.05 in | 1.27 mm | 28 AWG | 100 | 2 | Ribbon Cable | Free Hanging (In-Line) | Closed End | Black | 30 Áin | 0.76 Ám | Female Socket | 1.27 mm | 0.05 " | Gold | Receptacle | IDC | ||||||||||||||||||||||||||||||||
 TE Connectivity AMP Connectors | 20 | 2 | Surface Mount | Board Lock Pick and Place | Male Pin | Header | Automotive General Purpose Medical Military Telecommunications | 3.81 Ám | 6.35 mm | 500 mA | Shrouded - 4 Wall | Tin | 105 ░C | -65 ░C | Circular | Black | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | Phosphor Bronze | Gold | Push-Pull | 0.76 Ám | 30 Áin | UL94 V-0 | 5.74 mm | 0.226 in | Solder | 1.27 mm | 0.05 in | 0.12 in | 3.05 mm | All | ||||||||||||||||
 TE Connectivity AMP Connectors | 10 | 2 | Surface Mount | Board Lock | Male Pin | Header | Automotive General Purpose Medical Military Telecommunications | 3.81 Ám | 9.91 mm | 500 mA | Shrouded - 4 Wall | Tin | 105 ░C | -65 ░C | Circular | Black | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | Phosphor Bronze | Gold | Push-Pull | 0.76 Ám | 30 Áin | UL94 V-0 | 9.33 mm | Solder | 1.27 mm | 0.05 in | 0.12 in | 3.05 mm | All | 0.367 in | ||||||||||||||||
 TE Connectivity AMP Connectors | 20 | 2 | Right Angle Surface Mount | Board Lock Solder Retention | Male Pin | Header | Automotive General Purpose Medical Military Telecommunications | 3.81 Ám | 500 mA | Shrouded - 4 Wall | Tin | 105 ░C | -65 ░C | Circular | Black | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | Brass | Gold | Push-Pull | 0.76 Ám | 30 Áin | UL94 V-0 | Solder | 1.27 mm | 0.05 in | All | 0.213 " | 5.4 mm | |||||||||||||||||||
TE Connectivity AMP Connectors | 10 | 2 | Surface Mount | Board Lock | Male Pin | Header | 500 mA | Shrouded - 4 Wall | Tin-Lead | 105 ░C | -65 ░C | Circular | Black | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | Phosphor Bronze | Gold | Push-Pull | 0.76 Ám | 30 Áin | UL94 V-0 | 5.74 mm | 0.226 in | Solder | 1.27 mm | 0.05 in | 0.12 in | 3.05 mm | All | |||||||||||||||||||
 TE Connectivity AMP Connectors | 80 | AMPMODU 50/50 Grid Series | Cap (Cover) | ||||||||||||||||||||||||||||||||||||||||||||||
 TE Connectivity AMP Connectors | 40 | 2 | Surface Mount | Board Lock | Male Pin | Header | 500 mA | Shrouded - 4 Wall | Tin-Lead | 105 ░C | -65 ░C | Circular | Black | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | Phosphor Bronze | Gold | Push-Pull | 0.76 Ám | 30 Áin | UL94 V-0 | 5.74 mm | 0.226 in | Solder | 1.27 mm | 0.05 in | 0.12 in | 3.05 mm | All | |||||||||||||||||||
 TE Connectivity AMP Connectors | 100 | 2 | Surface Mount | Board Lock | Female Socket | Receptacle | 3.81 Ám | 6.35 mm 8.13 mm 9.91 mm | Tin | 105 ░C | -65 ░C | Square | Black | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | Copper Alloy | Gold | Push-Pull | 0.76 Ám | 30 Áin | 4.75 mm | 0.187 in | Solder | 1.27 mm | 0.05 in | All | Board to Board Cable | |||||||||||||||||||||
 TE Connectivity AMP Connectors | 100 | 2 | Surface Mount | Board Lock Pick and Place | Male Pin | Header | Automotive General Purpose Medical Military Telecommunications | 3.81 Ám | 6.35 mm | 500 mA | Shrouded - 4 Wall | Tin | 105 ░C | -65 ░C | Circular | Black | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | Phosphor Bronze | Gold | Push-Pull | 0.76 Ám | 30 Áin | UL94 V-0 | 5.74 mm | 0.226 in | Solder | 1.27 mm | 0.05 in | 0.12 in | 3.05 mm | All | ||||||||||||||||
 TE Connectivity AMP Connectors | 100 | 2 | Right Angle Surface Mount | Board Lock Solder Retention | Male Pin | Header | 500 mA | Shrouded - 4 Wall | Tin | 105 ░C | -65 ░C | Circular | Black | 0.05 in | 1.27 mm | Liquid Crystal Polymer (LCP) | Brass | Gold | Push-Pull | 0.76 Ám | 30 Áin | UL94 V-0 | Solder | 1.27 mm | 0.05 in | All | 0.213 " | 5.4 mm |
