CGS RLC73 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

RES, R082, 1%, 1W, 2512, THICK FILM ROHS COMPLIANT: YES

...

Part	Number of Terminations [custom]	Supplier Device Package	Power (Watts)	Resistance	Height - Seated (Max) [Max]	Height - Seated (Max)	Features	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Composition	Temperature Coefficient	Tolerance	Height - Seated (Max) [Max]	Supplier Device Package	Package / Case	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Power (Watts)	Temperature Coefficient	Power (Watts)
TE Connectivity AMP Connectors RLC73N3AR082FTDF	2	2512	1 W	0.082 Ohms	0.033 in	0.84 mm	Current Sense	2512 (6432 Metric)	155 C	-55 C	0.25 in	0.122 in	6.35 mm	3.1 mm	Thick Film	300 ppm/°C	1 %
TE Connectivity AMP Connectors RLC73PD2BR665FTD	2		1 W	665 mOhms	0.026 in		Current Sense	1206 (3216 Metric)	155 C	-55 C	0.122 "	0.061 in	3.1 mm	1.55 mm	Thick Film	50 ppm/░C	1 %	0.65 mm	1206
TE Connectivity AMP Connectors RLC73PH3AR02FTDG	2	2512	2 W	0.02 Ohms			Current Sense	2512	155 C	-55 C	0.25 in	0.122 in	6.35 mm	3.1 mm	Thick Film	100 ppm/°C	1 %			6332 Metric	0.7 mm	0.028 "
TE Connectivity AMP Connectors RLC73PV2AR022FTD	2		0.25 W	22 mOhms	0.026 in		Current Sense	0805	155 C	-55 C	0.079 in	0.049 "	2 mm	1.25 mm	Thick Film	600 ppm/°C	1 %	0.65 mm	0805				0.25 W
TE Connectivity AMP Connectors RLC73PV2AR033FTD	2		0.25 W	33 mOhms	0.026 in		Current Sense	0805	155 C	-55 C	0.079 in	0.049 "	2 mm	1.25 mm	Thick Film	600 ppm/°C	1 %	0.65 mm	0805				0.25 W
TE Connectivity AMP Connectors RLC73PM2HR039FTE	2	2010	1 W	39 mOhms			Current Sense	2010 (5025 Metric)	155 C	-55 C	0.197 in	0.098 in	5 mm	2.5 mm	Thick Film		1 %				0.75 mm	0.03 "		±400ppm/°C
TE Connectivity AMP Connectors RLC73PV2BR02FTDF	2		0.5 W	0.02 Ohms	0.026 in		Current Sense	1206 (3216 Metric)	155 C	-55 C	0.122 "	0.061 in	3.1 mm	1.55 mm	Thick Film	600 ppm/°C	1 %	0.65 mm	1206				0.5 W
TE Connectivity AMP Connectors RLC73K2BR374FTD	2		0.25 W	374 mOhms	0.026 in		Current Sense	1206 (3216 Metric)	155 C	-55 C	0.122 "	0.061 in	3.1 mm	1.55 mm	Thick Film	200 ppm/°C	1 %	0.65 mm	1206				0.25 W
TE Connectivity AMP Connectors RLC73PD2ER383FTD	2		0.75 W	383 mOhms	0.026 in		Current Sense	1210	155 C	-55 C	0.122 "	0.102 in	3.1 mm	2.6 mm	Thick Film	50 ppm/░C	1 %	0.65 mm	1210	3225 Metric					3/4W
TE Connectivity AMP Connectors RLC73PD2BR402FTD	2		1 W	402 mOhms	0.026 in		Current Sense	1206 (3216 Metric)	155 C	-55 C	0.122 "	0.061 in	3.1 mm	1.55 mm	Thick Film	50 ppm/░C	1 %	0.65 mm	1206
