VLS-HBX Series
Manufacturer: TDK Corporation
Beta
⌘K
POWER INDUCTOR, 4.7UH, SHIELDED, 2.11A ROHS COMPLIANT: YES
| Part | Inductance Frequency - Test | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Current Rating (Amps) | Current - Saturation (Isat) | Operating Temperature [Min] | Operating Temperature [Max] | Tolerance | Inductance | Mounting Type | Shielding | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Supplier Device Package | DC Resistance (DCR) [Max] | Material - Core | Package / Case | Package / Case | Type | DC Resistance (DCR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TDK Corporation | 1 MHz | 3 mm | 0.118 in | 3 mm | 0.118 " | 2.01 A | 1.9 A | -40 C | 105 ░C | 20 % | 4.7 ÁH | Surface Mount | Shielded | 1.2 mm | 0.047 " | 1212 | 201 mOhm | Metal | 3030 Metric | 1212 | Drum Core Wirewound | |
 TDK Corporation | 1 MHz | 3 mm | 0.118 in | 3 mm | 0.118 " | 2.23 A | 2.51 A | -40 C | 105 ░C | 20 % | 4.7 ÁH | Surface Mount | Shielded | 1.2 mm | 0.047 " | 201 mOhm | Metal | Nonstandard | Drum Core Wirewound | |||
 TDK Corporation | 1 MHz | 4 mm | 0.157 " | 4 mm | 0.157 in | 3.33 A | -40 C | 105 ░C | 20 % | 3.3 µH | Surface Mount | Shielded | 1.2 mm | 0.047 " | 119 mOhm | Metal | Nonstandard | Drum Core Wirewound | ||||
TDK Corporation | 1 MHz | 3 mm | 0.118 in | 3 mm | 0.118 " | 1.12 A | 1.09 A | -40 C | 105 ░C | 20 % | 22 µH | Surface Mount | Shielded | 1.2 mm | 0.047 " | Metal | Nonstandard | Drum Core Wirewound | 761 mOhm | |||
TDK Corporation | 1 MHz | 3 mm | 0.118 in | 3 mm | 0.118 " | 6.78 A | 9.11 A | -40 C | 105 ░C | 30 % | 330 nH | Surface Mount | Shielded | 1.2 mm | 0.047 " | 30 mOhm | Metal | Nonstandard | Drum Core Wirewound | |||
TDK Corporation | 1 MHz | 3 mm | 0.118 in | 3 mm | 0.118 " | 6.1 A | 8.6 A | -40 C | 105 ░C | 30 % | 330 nH | Surface Mount | Shielded | 1.2 mm | 0.047 " | 1212 | 30 mOhm | Metal | 3030 Metric | 1212 | Drum Core Wirewound | |
TDK Corporation | 1 MHz | 3 mm | 0.118 in | 3 mm | 0.118 " | 5.13 A | 5.5 A | -40 C | 105 ░C | 20 % | 1 µH | Surface Mount | Shielded | 1.2 mm | 0.047 " | 47 mOhm | Metal | Nonstandard | Drum Core Wirewound | |||
 TDK Corporation | 1 MHz | 4 mm | 0.157 " | 4 mm | 0.157 in | 1.15 A | 1.26 A | -40 C | 105 ░C | 20 % | 22 µH | Surface Mount | Shielded | 1.2 mm | 0.047 " | 1616 | 684 mOhm | Metal | 1616 (4040 Metric) | Drum Core Wirewound |
