TR Series

Manufacturer: YAGEO

Catalog

THICK FILM RESISTORS - SMD 22KOHMS 1/8W 0805 30%

Part	Composition	Temperature Coefficient	Tolerance (Negative)	Features	Power (Watts)	Power (Watts) Options	Operating Temperature (Max)	Operating Temperature (Min)	Size / Dimension Length	Size / Dimension Width	Height - Seated (Max)	Number of Terminations	Resistance	Package Name	Package / Case
YAGEO TR0805NR-0722KL	Thick Film	100 ppm/°C	30 %	Moisture Resistant	0.125 W	1/8W	155 °C	-55 °C	0.079 in	0.049 in	0.024 in	2	22 kOhm	0805	0805 (2012 Metric)
YAGEO TR1206MR-071KL	Thick Film	100 ppm/°C	20 %	Moisture Resistant	250 mW	1/4W	155 °C	-55 °C	0.122 in	0.063 in	0.026 in	2	1 kOhm	1206	1206 (3216 Metric)
YAGEO TR1206NR-073K3L	Thick Film	100 ppm/°C	30 %	Moisture Resistant	250 mW	1/4W	155 °C	-55 °C	0.122 in	0.063 in	0.026 in	2	3.3 kOhm	1206	1206 (3216 Metric)
YAGEO TR0603KR-071KL	Thick Film	100 ppm/°C	10 %	Moisture Resistant	100 mW	1/10W	125 °C	-55 °C	0.063 in	0.031 in	0.022 in	2	1 kOhm	0603	0603 (1608 Metric)
YAGEO TR0805KR-071KL	Thick Film	100 ppm/°C	10 %	Moisture Resistant	0.125 W	1/8W	155 °C	-55 °C	0.079 in	0.049 in	0.024 in	2	1 kOhm	0805	0805 (2012 Metric)
YAGEO TR1206NR-07300RL	Thick Film	100 ppm/°C	30 %	Moisture Resistant	250 mW	1/4W	155 °C	-55 °C	0.122 in	0.063 in	0.026 in	2	300 Ohm	1206	1206 (3216 Metric)
