H16B Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

CONN HOOD SIDE ENTRY SZ16B PG21

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Lock Location	Housing Color	Thread Size	Size	Ingress Protection	Connector Type	Operating Temperature [Max]	Operating Temperature [Min]	Housing Material	Style	Housing Finish	Features	Size
TE Connectivity AMP Connectors H16B-TSB-PG21	43 mm	3.681 in	60 mm	2.362 in	93.5 mm	1.693 "	Locking Clip (2) on Hood	Gray	PG21	16 B	IP65 - Dust Tight Water Resistant	Hood	125 °C	-40 C	Aluminum Alloy Die Cast	Side Entry	Powder Coated
TE Connectivity AMP Connectors H16B-AG	45.7 mm	4.575 "	29.6 mm	1.165 in	116.2 mm	1.799 in	Locking Clip (2) on Base Bottom	Gray		16 B	IP65 - Dust Tight Water Resistant	Base - Panel Mount	125 °C	-40 C	Aluminum Alloy Die Cast	Bottom Entry	Powder Coated
TE Connectivity AMP Connectors H16B-AD-BO	45.7 mm	4.575 "	29.6 mm	1.165 in	116.2 mm	1.799 in	Locking Clip (2) on Hood			16 B	IP65 - Dust Tight Water Resistant	Base - Panel Mount	125 °C	-40 C	Aluminum Alloy Die Cast	Bottom Entry	Powder Coated	Cover
TE Connectivity AMP Connectors H16B-TS-PG21	43 mm	3.681 in	60 mm	2.362 in	93.5 mm	1.693 "	Locking Clip (2) on Base Bottom	Gray	PG21	16 B	IP65 - Dust Tight Water Resistant	Hood	125 °C	-40 C	Aluminum Alloy Die Cast	Side Entry	Powder Coated
TE Connectivity AMP Connectors H16BPR-AGCT-EMC-C	60 mm	5.098 in	21.9 mm	0.862 in	129.5 mm	2.362 in	Screw Locks on Hood	Black			IP68 - Dust Tight Waterproof	Base - Panel Mount	125 °C	-40 C	Aluminum Alloy Die Cast	Bottom Entry	Powder Coated	Corrosion Resistant EMC Resistant	H16B
TE Connectivity AMP Connectors H16B-TS-RO-M32	43 mm	3.681 in	60 mm	2.362 in	93.5 mm	1.693 "	Locking Clip (1) on Base Bottom	Gray	M32	16 B	IP65 - Dust Tight Water Resistant	Hood	125 °C	-40 C	Aluminum Alloy Die Cast	Side Entry	Powder Coated
TE Connectivity AMP Connectors H16B-SGRH-LB-M32							Locking Clip (1) on Base Bottom	Gray	M32	16 B	IP65 - Dust Tight Water Resistant	Base - Box Mount	125 °C	-40 C	Aluminum Alloy Die Cast	Side Entry	Powder Coated
TE Connectivity AMP Connectors H16B-TSBH-PG29	43 mm	3.681 in	76 mm	2.992 in	93.5 mm	1.693 "	Locking Clip (2) on Hood	Gray	PG29	16 B	IP65 - Dust Tight Water Resistant	Hood	125 °C	-40 C	Aluminum Alloy Die Cast	Side Entry	Powder Coated
TE Connectivity AMP Connectors H16B-SDRH-BO-PG29	57 mm	4.606 in	76.1 mm	2.996 in	117 mm	2.244 "	Locking Clip (2) on Hood	Gray	PG29	16 B	IP65 - Dust Tight Water Resistant	Base - Box Mount	125 °C	-40 C	Aluminum Alloy Die Cast	Side Entry	Powder Coated	Cover
TE Connectivity AMP Connectors H16B-AG-SL	45.7 mm	4.575 "	29.8 mm	1.173 "	116.2 mm	1.799 in	Locking Clip (2) on Base Bottom	Gray		16 B	IP65 - Dust Tight Water Resistant	Base - Panel Mount	125 °C	-40 C	Aluminum Alloy Die Cast	Bottom Entry	Powder Coated
