LRB6SP Series

Catalog

LED RED CLEAR 2PLCC SMD R/A

Part	Configuration	Current - Test	Lens Style	Wavelength - Dominant	Lens Size [diameter]	Millicandela Rating	Supplier Device Package	Mounting Type	Voltage - Forward (Vf) (Typ)	Color	Lens Color	Package / Case	Height (Max) [z]	Viewing Angle	Lens Transparency	Size / Dimension [x]	Size / Dimension [y]	Height (Max) [Max] [z]
ams-OSRAM USA INC. LR B6SP-CADB-1-1	Standard	140 mA	Round with Flat Top	623 nm	3.4 mm	495 mcd	2-PLCC	Right Angle Surface Mount	2.1 V	Red	Colorless	2-PLCC	4.7 mm	120 °	Clear	4.8 mm	3.8 mm
ams-OSRAM USA INC. LR B6SP-DBFA-1-G3R3-140-R33-Z		140 mA	Round with Flat Top	623 nm	3.4 mm	9800 mcd	2-PLCC	Right Angle Surface Mount	2.2 V	Red	Colorless	2-SMD Boomerang		120 °	Clear	4.6 mm	4.6 mm	3.8 mm
