SV Series

Catalog

MULTILAYER CERAMIC CAPACITORS MLCC - LEADED 600 VDC 4700 PF X7R 10 % 5.08 MM

Part	Applications	Temperature Coefficient	Lead Style	Tolerance	Voltage - Rated	Capacitance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Features	Package / Case	Lead Spacing	Lead Spacing	Mounting Type	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Rated	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Lead Spacing
KYOCERA AVX SV13CC472KAR	General Purpose	X7R	Straight	10 %	630 V	0.0047 µF	0.36 in	9.14 mm	High Voltage	Radial	0.2 in	5.08 mm	Through Hole	7.62 mm	5.08 mm	0.3 "	0.2 in	-55 C	125 °C
KYOCERA AVX SV13AC103MAR	General Purpose	X7R	Straight	20 %	1000 V	10000 pF	0.36 in	9.14 mm	High Voltage	Radial	0.2 in	5.08 mm	Through Hole	7.62 mm	5.08 mm	0.3 "	0.2 in	-55 C	125 °C	1 kV
KYOCERA AVX SV05AC224KAA	General Purpose	X7R	Straight	10 %	1000 V	0.22 µF			High Voltage	Radial	0.375 in	9.52 mm	Through Hole	11.9 mm	5.08 mm	0.469 in	0.2 in	-55 C	125 °C	1 kV	0.402 in	10.2 mm
KYOCERA AVX SV14GA222JAR	General Purpose	C0G NP0	Straight	5 %	2000 V	2200 pF	0.461 in		High Voltage	Radial	0.2 in	5.08 mm	Through Hole	10.2 mm	5.08 mm	0.402 in	0.2 in	-55 C	125 °C	2 kV		11.7 mm
KYOCERA AVX SV09AC105KAR	General Purpose	X7R	Straight	10 %	1000 V	1 µF	0.72 in	18.3 mm	High Voltage	Radial		0.673 "	Through Hole	19.6 mm	5.08 mm	0.772 in	0.2 in	-55 C	125 °C	1 kV			17.1 mm
KYOCERA AVX SV05HC103KAR	General Purpose	X7R	Straight	10 %	3000 V	10000 pF			High Voltage	Radial	0.375 in	9.52 mm	Through Hole	11.9 mm	5.08 mm	0.469 in	0.2 in	-55 C	125 °C	3 kV	0.402 in	10.2 mm
