IP Series
Manufacturer: DB Unlimited
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
PIEZO BUZZERS & AUDIO INDICATORS PIEZO INDICATOR
| Part | Technology | Operating Mode | Driver Circuitry | Operating Temperature (Max) | Operating Temperature (Min) | Frequency | Termination | Input Type | Sound Pressure Level (SPL) | Port Location | Size / Dimension Diameter | Voltage Range (Max) | Voltage Range (Min) | Height - Seated (Max) | Voltage - Rated | Mounting Type | Current - Supply |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 DB Unlimited | Piezo | Dual Tone | Indicator Internally Driven | 60 °C | -20 °C | 3.2 kHz | Wire Leads | DC | 115 dB | Top | 1.969 in | 16 V | 6 VDC | 1.496 in | 12 VAC | Flange Panel Mount | 65 mA |
 DB Unlimited | Piezo | Dual Tone | Indicator Internally Driven | 85 °C | -40 °C | 3.2 kHz | Wire Leads | DC | Top | 1.161 in | 28 V | 3 V | 0.965 in | 24 VAC | Flange Panel Mount | 30 mA | |
 DB Unlimited | Piezo | Siren | Indicator Internally Driven | 60 °C | -20 °C | 4 kHz | Wire Leads | DC | 125 dB | Top | 2.047 in | 15 V | 6 VDC | 1.969 in | 12 VAC | Flange Panel Mount | 280 mA |
 DB Unlimited | Piezo | Siren | Indicator Internally Driven | 60 °C | -20 °C | 3.1 kHz | Wire Leads | DC | 125 dB | Top | 15 V | 9 V | 1.28 in | 12 VAC | Flange Panel Mount | 120 mA | |
 DB Unlimited | Piezo | Single Tone | Indicator Internally Driven | 70 °C | -30 °C | 3.5 kHz | PC Pins | DC | 100 dB | Top | 1.181 in | 24 V | 3 V | 0.866 in | 9 VAC | Through Hole | 20 mA |
