C44U Series
Manufacturer: KEMET
Beta
⌘K
FILM CAPACITORS 900VDC 270UF 10%
| Part | Applications | ESR (Equivalent Series Resistance) | Tolerance | Capacitance | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Termination | Package / Case | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Size / Dimension [diameter] | Dielectric Material | Voltage Rating - DC | Features | Lead Spacing | Lead Spacing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KEMET | General Purpose | 1.8 mOhm | 10 % | 270 µF | 97 mm | 3.819 in | Threaded Male | Can Radial | 90 °C | -40 C | Chassis Stud Mount | 2.992 " 76 mm | Polypropylene (PP) Metallized | 900 VDC | Long Life | 1.248 in | 31.7 mm |
