087891 Series

Manufacturer: Molex

Catalog

CONN HEADER VERT 40POS 2.54MM

Part	Style	Applications	Connector Type	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Length - Post	Contact Length - Post	Shrouding	Contact Shape	Number of Positions Loaded	Contact Finish - Post	Insulation Color	Contact Material	Termination	Contact Finish - Mating	Contact Type	Number of Positions	Contact Length - Mating [x]	Contact Length - Mating	Overall Contact Length	Overall Contact Length	Insulation Material	Number of Rows	Material Flammability Rating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Pitch - Mating	Pitch - Mating	Fastening Type	Insulation Height [z]	Insulation Height [z]	Mounting Type	Contact Length - Post [x]	Contact Length - Post [x]	Contact Length - Mating [x]	Current Rating (Amps)	Voltage Rating	Operating Temperature [Max]	Operating Temperature [Min]	Contact Finish Thickness - Mating
Molex 0878914005	Board to Board Cable	Automotive General Purpose Medical Telecommunications	Breakaway Header	74.8 Áin	1.9 Ám	0.117 in	2.97 mm	Unshrouded	Square	All	Tin	Black	Copper Alloy	Solder	Gold	Male Pin	40	0.23 in	5.84 mm	11.3 mm	0.445 "	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	30 Áin	0.76 Ám	0.1 in	2.54 mm	Push-Pull	0.098 in	2.5 mm	Through Hole
Molex 0878910204	Board to Board Cable	Automotive General Purpose Medical Telecommunications	Breakaway Header	74.8 Áin	1.9 Ám	0.117 in	2.97 mm	Unshrouded	Square	All	Tin	Black	Copper Alloy	Solder	Gold	Male Pin	2	0.23 in	5.84 mm	11.3 mm	0.445 "	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	15 µin	0.38 µm	0.1 in	2.54 mm	Push-Pull	0.098 in	2.5 mm	Through Hole
Molex 0878910206	Board to Board Cable	Automotive General Purpose Medical Telecommunications	Breakaway Header	100 µin	2.54 µm	0.117 in	2.97 mm	Unshrouded	Square	All	Tin	Black	Copper Alloy	Solder		Male Pin	2	0.23 in	5.84 mm	11.3 mm	0.445 "	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	100 çin	2.54 çm	0.1 in	2.54 mm	Push-Pull	0.098 in	2.5 mm	Through Hole
Molex 0878910606	Board to Board Cable	Automotive General Purpose Medical Telecommunications	Breakaway Header	100 µin	2.54 µm	0.117 in	2.97 mm	Unshrouded	Square	All	Tin	Black	Copper Alloy	Solder		Male Pin	6	0.23 in	5.84 mm	11.3 mm	0.445 "	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	100 çin	2.54 çm	0.1 in	2.54 mm	Push-Pull	0.098 in	2.5 mm	Through Hole
Molex 0878914007	Board to Board Cable		Breakaway Header	78.7 çin	2 çm			Unshrouded	Square	All	Tin	Black	Copper Alloy	Solder	Gold	Male Pin	40	0.23 in	5.84 mm	12.15 mm	0.478 in	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	15 µin	0.38 µm	0.1 in	2.54 mm	Push-Pull	0.098 in	2.5 mm	Through Hole	0.15 in	3.81 mm
Molex 0878910306	Board to Board Cable	Automotive General Purpose Medical Telecommunications	Breakaway Header	100 µin	2.54 µm	0.117 in	2.97 mm	Unshrouded	Square	All	Tin	Black	Copper Alloy	Solder		Male Pin		0.23 in	5.84 mm	11.3 mm	0.445 "	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	100 çin	2.54 çm	0.1 in	2.54 mm	Push-Pull	0.098 in	2.5 mm	Through Hole
Molex 0878910210	Board to Board Cable	Automotive General Purpose Medical Telecommunications	Breakaway Header	100 µin	2.54 µm	0.117 in	2.97 mm	Unshrouded	Square	All	Tin	Black	Copper Alloy	Solder		Male Pin	2	1 in		31 mm	1.22 in	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	100 çin	2.54 çm	0.1 in	2.54 mm	Push-Pull	0.098 in	2.5 mm	Through Hole			25.4 mm
Molex 0878914006	Board to Board Cable	Automotive General Purpose Medical Telecommunications	Breakaway Header	100 µin	2.54 µm	0.117 in	2.97 mm	Unshrouded	Square	All	Tin	Black	Copper Alloy	Solder		Male Pin	40	0.23 in	5.84 mm	11.3 mm	0.445 "	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	100 çin	2.54 çm	0.1 in	2.54 mm	Push-Pull	0.098 in	2.5 mm	Through Hole
Molex 0878910808	Board to Board Cable	Automotive General Purpose Medical Telecommunications	Breakaway Header	78.7 çin	2 çm	0.17 in	4.32 mm	Unshrouded	Square	All	Tin	Black	Copper Alloy	Solder	Gold	Male Pin	8			20.53 mm	0.808 in	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	15 µin	0.38 µm	0.1 in	2.54 mm	Push-Pull	0.098 in	2.5 mm	Through Hole				3 A	250 VDC	105 ░C	-55 °C
Molex 0878910101	Board to Board Cable		Breakaway Header			0.117 in	2.97 mm	Unshrouded	Square	All		Black	Copper Alloy	Solder	Gold	Male Pin	1	0.23 in	5.84 mm	11.3 mm	0.445 "	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0					Push-Pull	0.098 in	2.5 mm	Through Hole								Flash
