Surface Mount Fuses SM 2410 Slow Blow, 12A
Surface Mount Fuses SM 2410 Slow Blow, 12A
| Part | Voltage Rating - DC | Approval Agency | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Response Time | Voltage Rating - AC | Package / Case | Current Rating (Amps) | Melting I²t | Fuse Type | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Breaking Capacity @ Rated Voltage | DC Cold Resistance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | 75 V | CE cURus | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | Slow Blow | 50 V | 2-SMD Square End Block | 12 Amps | 244 I²t | Board Mount (Cartridge Style Excluded) | Surface Mount | -55 C | 125 °C | 100 A 500 A | |
 Bel Fuse Inc. | 125 VDC | AEC-Q200 CE cURus | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | Slow Blow | 125 V | 2-SMD Square End Block | 1 A | 1.5 I²t | Board Mount (Cartridge Style Excluded) | Surface Mount | -55 C | 125 °C | 50 A 100 A | |
 Bel Fuse Inc. | 125 VDC | AEC-Q200 CE cURus | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | Slow Blow | 125 V | 2-SMD Square End Block | 1.5 A | 3.3 | Board Mount (Cartridge Style Excluded) | Surface Mount | -55 C | 125 °C | 50 A 100 A | |
Bel Fuse Inc. | 125 VDC | AEC-Q200 CE cURus | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | Slow Blow | 125 V | 2-SMD Square End Block | 3 A | 13 I²t | Board Mount (Cartridge Style Excluded) | Surface Mount | -55 C | 125 °C | 50 A 100 A | |
Bel Fuse Inc. | 125 VDC | AEC-Q200 CE cURus | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | Slow Blow | 125 V | 2-SMD Square End Block | 0.5 A | 0.27 I²t | Board Mount (Cartridge Style Excluded) | Surface Mount | -55 C | 125 °C | 50 A 100 A | |
Bel Fuse Inc. | 125 VDC | AEC-Q200 CE cURus | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | Slow Blow | 125 V | 2-SMD Square End Block | 1.5 A | 3.3 | Board Mount (Cartridge Style Excluded) | Surface Mount | -55 C | 125 °C | 50 A 100 A | 0.095 Ohms |
Bel Fuse Inc. | 125 VDC | AEC-Q200 CE cURus | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | Slow Blow | 125 V | 2-SMD Square End Block | 2 A | 6 | Board Mount (Cartridge Style Excluded) | Surface Mount | -55 C | 125 °C | 50 A 100 A | |
Bel Fuse Inc. | 125 VDC | AEC-Q200 CE cURus | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | Slow Blow | 125 V | 2-SMD Square End Block | 4 A | 24 | Board Mount (Cartridge Style Excluded) | Surface Mount | -55 C | 125 °C | 50 A 100 A | |
Bel Fuse Inc. | 125 VDC | AEC-Q200 CE cURus | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | Slow Blow | 125 V | 2-SMD Square End Block | 375 mA | 0.14 | Board Mount (Cartridge Style Excluded) | Surface Mount | -55 C | 125 °C | 50 A 100 A | |
Bel Fuse Inc. | 125 VDC | AEC-Q200 CE cURus | 6.1 mm | 0.1 " | 0.1 in | 0.1 in | 2.54 mm | 0.24 " | Slow Blow | 125 V | 2-SMD Square End Block | 4 A | 24 | Board Mount (Cartridge Style Excluded) | Surface Mount | -55 C | 125 °C | 50 A 100 A |
