2ED21084 Series
Manufacturer: INFINEON
Beta
⌘K
THE 2ED21084S06J IS A 650 V, 0.7 A HALF-BRIDGE GATE DRIVER WITH INTEGRATED BOOTSTRAP DIODE (DSO-14 PACKAGE)
| Part | Gate Type | Mounting Type | Channel Type | Input Type | Rise / Fall Time (Typ) [custom] | Rise / Fall Time (Typ) [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Driven Configuration | Voltage - Supply [Max] | Voltage - Supply [Min] | Current - Peak Output (Source, Sink) [custom] | Current - Peak Output (Source, Sink) [custom] | Supplier Device Package | Number of Drivers | Logic Voltage - VIL, VIH [custom] | Logic Voltage - VIL, VIH [custom] | Package / Case | Package / Case | High Side Voltage - Max (Bootstrap) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | IGBT MOSFET (N-Channel) N-Channel MOSFET | Surface Mount | Synchronous | Non-Inverting | 35 ns | 100 ns | 125 °C | -40 °C | Half-Bridge | 20 V | 10 VDC | 290 mA | 700 mA | PG-DSO-14-49 | 1 | 1.7 V | 1.1 V | 0.154 in 3.9 mm | 14-SOIC | 650 V |
