630M Series
Manufacturer: EDAC Inc.
Beta
⌘K
D-SUB STANDARD CONNECTORS RIGHT ANGLE D-SUB CONNECTOR
| Part | Shell Material, Finish | Contact Finish Thickness | Connector Style | Current Rating (Amps) | Features | Contact Finish | Number of Positions | Connector Type | Termination | Flange Feature | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Type | Material Flammability Rating | Backset Spacing | Backset Spacing | Number of Rows [custom] | Mounting Type | Shell Size, Connector Layout | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Shell Size, Connector Layout | Shell Size, Connector Layout [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Nickel Plated Steel | Flash | D-Sub | 5 A | Mounting Brackets Shielded | Gold | 9 | Receptacle Female Sockets | Solder | 4-40 | 1 | DE E | Signal | UL94 V-0 | 9.4 mm | 0.37 in | 2 | Right Angle Through Hole | ||||||
 EDAC Inc. | Nickel Plated Steel | D-Sub | 5 A | Mounting Brackets Shielded | Gold | 15 | Receptacle Female Sockets | Solder | 4-40 | Signal | UL94 V-0 | 9.4 mm | 0.37 in | 2 | Right Angle Through Hole | 2 | 30 Áin | 0.76 Ám | ||||||
 EDAC Inc. | D-Sub | 5 A | Board Lock Mounting Brackets Shielded | Gold | 9 | Receptacle Female Sockets | Solder | Housing/Shell | 1 | DE E | Signal | UL94 V-0 | 9.4 mm | 0.37 in | 2 | Right Angle Through Hole | 15 µin | 0.38 µm | 4-40 | |||||
 EDAC Inc. | Flash | D-Sub | 5 A | Board Lock Mounting Brackets Shielded | Gold | 15 | Receptacle Female Sockets | Solder | Housing/Shell | Signal | UL94 V-0 | 9.4 mm | 0.37 in | 2 | Right Angle Through Hole | 2 | 4-40 | |||||||
 EDAC Inc. | Flash | D-Sub | 5 A | Mounting Brackets Shielded | Gold | 9 | Receptacle Female Sockets | Solder | 4-40 | 1 | DE E | Signal | UL94 V-0 | 9.4 mm | 0.37 in | 2 | Right Angle Through Hole | |||||||
 EDAC Inc. | Nickel Plated Steel | Flash | D-Sub | 5 A | Shielded | Gold | 9 | Receptacle Female Sockets | Solder | Housing/Shell (Unthreaded) | 1 | DE E | Signal | UL94 V-0 | 9.4 mm | 0.37 in | 2 | Right Angle Through Hole | ||||||
 EDAC Inc. | Flash | D-Sub | 5 A | Board Lock Mounting Brackets Shielded | Gold | 25 | Receptacle Female Sockets | Solder | Housing/Shell | Signal | UL94 V-0 | 9.4 mm | 0.37 in | 2 | Right Angle Through Hole | 4-40 | B DB | 3 | ||||||
 EDAC Inc. | Nickel Plated Steel | Flash | D-Sub | 5 A | Mounting Brackets Shielded | Gold | 25 | Receptacle Female Sockets | Solder | 4-40 | Signal | UL94 V-0 | 9.4 mm | 0.37 in | 2 | Right Angle Through Hole | B DB | 3 | ||||||
 EDAC Inc. | Flash | D-Sub | 5 A | Mounting Brackets Shielded | Gold | 15 | Receptacle Female Sockets | Solder | 4-40 | Signal | UL94 V-0 | 9.4 mm | 0.37 in | 2 | Right Angle Through Hole | 2 | ||||||||
 EDAC Inc. | Nickel Plated Steel | D-Sub | 5 A | Board Lock Mounting Brackets Shielded | Gold | 50 | Receptacle Female Sockets | Solder | Housing/Shell | 5 | D DD | Signal | UL94 V-0 | 9.4 mm | 0.37 in | 3 | Right Angle Through Hole | 15 µin | 0.38 µm | 4-40 |
