VLS-E-CA Series

Catalog

POWER INDUCTORS - SMD RECOMMENDED ALT 810-VLS6045EX-100M-H

Part	Inductance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Inductance Frequency - Test	Tolerance	Material - Core	Mounting Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Type	Current - Saturation (Isat)	DC Resistance (DCR) [Max]	Current Rating (Amps)	Package / Case	Shielding	Operating Temperature [Min]	Operating Temperature [Max]	DC Resistance (DCR)
TDK Corporation VLS201612ET-100M-CA	10 µH	1.2 mm	0.047 "	1 MHz	20 %	Ferrite	Surface Mount	1.6 mm	0.079 in	0.063 "	2 mm	Drum Core Wirewound	470 mA	1.026 Ohm	0.5 A	Nonstandard	Shielded	-40 C	105 ░C
TDK Corporation VLS4012ET-150M-CA	15 µH	1.2 mm	0.047 "	1 MHz	20 %	Ferrite	Surface Mount	4 mm	0.157 in	0.157 "	4 mm	Drum Core Wirewound	700 mA	372 mOhm	1.05 A	Nonstandard	Shielded	-40 C	105 ░C
TDK Corporation VLS4012ET-470M-CA	47 µH	1.2 mm	0.047 "	1 MHz	20 %	Ferrite	Surface Mount	4 mm	0.157 in	0.157 "	4 mm	Drum Core Wirewound	460 mA	1.02 Ohm	0.61 A	Nonstandard	Shielded	-40 C	105 ░C
TDK Corporation VLS2012ET-3R3M-CA	3.3 µH	1.2 mm	0.047 "	1 MHz	20 %	Ferrite	Surface Mount	2 mm	0.079 in	0.079 in	2 mm	Drum Core Wirewound	840 mA	228 mOhm	1 A	Nonstandard	Shielded	-40 C	105 ░C
TDK Corporation VLS201612ET-1R5N-CA	1.5 µH	1.2 mm	0.047 "	1 MHz	30 %	Ferrite	Surface Mount	1.6 mm	0.079 in	0.063 "	2 mm	Drum Core Wirewound	1.2 A	159 mOhm	1.25 A	Nonstandard	Shielded	-40 C	105 ░C
TDK Corporation VLS3012ET-1R5N-CA	1.5 µH	1.2 mm	0.047 "	1 MHz	30 %	Ferrite	Surface Mount	3 mm	0.118 "	0.118 in	3 mm	Drum Core Wirewound		76 mOhm	1.85 A	Nonstandard	Shielded	-40 C	105 ░C
TDK Corporation VLS4012ET-1R5N-CA	1.5 µH	1.2 mm	0.047 "	1 MHz	30 %	Ferrite	Surface Mount	4 mm	0.157 in	0.157 "	4 mm	Drum Core Wirewound	2.1 A		2.45 A	Nonstandard	Shielded	-40 C	105 ░C	72 mOhm
