2823382 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
9P,2MM,SHRD HDR,SRVT,2.8,0.76AU,
| Part | Termination | Contact Material | Contact Length - Post [x] | Contact Length - Post [x] | Number of Positions Loaded | Shrouding | Mounting Type | Number of Positions | Pitch - Mating [x] | Pitch - Mating [x] | Current Rating (Amps) | Contact Finish - Post | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Insulation Material | Voltage Rating | Contact Type | Fastening Type | Contact Length - Mating | Contact Length - Mating | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish - Mating | Insulation Height [custom] | Insulation Height [custom] | Contact Shape | Material Flammability Rating | Insulation Color | Connector Type | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Solder | Phosphor Bronze | 0.11 in | 2.8 mm | All | Shrouded - 2 Wall | Through Hole | 9 | 0.079 in | 2 mm | 2 A | Tin | 30 Áin | 0.76 Ám | 157.5 Áin | 4 Ám | Thermoplastic | 125 VAC | Male Pin | Detent Lock | 4 mm | 0.157 in | 125 °C | -40 °C | Gold | 5.51 mm | 0.217 in | Square | UL94 V-0 | Black | Header | 1 |
