XAN.M13 Series

Manufacturer: LEMO

Catalog

CONN PLUG MALE 13P GOLD SLDR CUP

Part	Cable Opening [Max]	Cable Opening [Min]	Cable Opening [Max]	Cable Opening [Min]	Orientation	Connector Type	Primary Material	Operating Temperature [Max]	Operating Temperature [Min]	Shell Material	Fastening Type	Backshell Material, Plating	Applications	Insert Material	Shell Size - Insert	Shielding	Mounting Type	Features	Color	Current Rating (Amps)	Ingress Protection	Number of Positions	Contact Finish - Mating
LEMO XAN.M13.BLA.6BZ	6.5 mm	0.209 in	0.256 in	5.3 mm	N (Normal)	Plug Male Pins	Plastic	170 °C	-50 °C	Sulfone	Push-Pull	Sulfone	Industrial Medical Testing Equipment & Measurement	Polyetheretherketone (PEEK)	M13	Unshielded	Free Hanging (In-Line)	Backshell	White	4 A	IP50 - Dust Protected	13	Gold
LEMO XAN.M13.GLA.6R	6.5 mm	0.209 in	0.256 in	5.3 mm	N (Normal)	Plug Male Pins	Plastic	170 °C	-50 °C	Sulfone	Push-Pull	Sulfone	Industrial Medical Testing Equipment & Measurement	Polyetheretherketone (PEEK)	M13	Unshielded	Free Hanging (In-Line)	Backshell	Gray Red	4 A	IP50 - Dust Protected	13	Gold
LEMO XAN.M13.GLA.6G	6.5 mm	0.209 in	0.256 in	5.3 mm	N (Normal)	Plug Male Pins	Plastic	170 °C	-50 °C	Sulfone	Push-Pull	Sulfone	Industrial Medical Testing Equipment & Measurement	Polyetheretherketone (PEEK)	M13	Unshielded	Free Hanging (In-Line)	Backshell	Gray	4 A	IP50 - Dust Protected	13	Gold
LEMO XAN.M13.GLA.3G	3.9 mm	0.098 in	0.154 in	2.5 mm	N (Normal)	Plug Male Pins	Plastic	170 °C	-50 °C	Sulfone	Push-Pull	Sulfone	Industrial Medical Testing Equipment & Measurement	Polyetheretherketone (PEEK)	M13	Unshielded	Free Hanging (In-Line)	Backshell	Gray	4 A	IP50 - Dust Protected	13	Gold
LEMO XAN.M13.GLA.6GZ	6.5 mm	0.209 in	0.256 in	5.3 mm	N (Normal)	Plug Male Pins	Plastic	170 °C	-50 °C	Sulfone	Push-Pull	Sulfone	Industrial Medical Testing Equipment & Measurement	Polyetheretherketone (PEEK)	M13	Unshielded	Free Hanging (In-Line)	Backshell	Gray	4 A	IP50 - Dust Protected	13	Gold
LEMO XAN.M13.GLA.6A	6.5 mm	0.209 in	0.256 in	5.3 mm	N (Normal)	Plug Male Pins	Plastic	170 °C	-50 °C	Sulfone	Push-Pull	Sulfone	Industrial Medical Testing Equipment & Measurement	Polyetheretherketone (PEEK)	M13	Unshielded	Free Hanging (In-Line)	Backshell	Blue Gray	4 A	IP50 - Dust Protected	13	Gold
