887-034 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 34POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row | Number of Positions [custom] | Number of Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Termination | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Color | Mounting Type | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Contact Type | Read Out | Gender | Pitch | Pitch | Termination Rows [custom] | Features | Number of Rows [custom] | Number of Positions/Bay/Row [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 34 | 34 | 1 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Solder | Non Specified - Single Edge | 125 °C | -40 C | Black | Right Angle Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Single | Female | 3.96 mm | 0.156 in | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 34 | 34 | 1 | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Wire Wrap | Non Specified - Single Edge | 125 °C | -40 C | Black | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Single | Female | 3.96 mm | 0.156 in | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 34 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Solder | Non Specified - Dual Edge | 125 °C | -40 C | Black | Board Edge Straddle Mount | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Dual | Female | 3.96 mm | 0.156 in | 2 | Card Extender | 2 | 17 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 34 | 34 | 1 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | Solder | Non Specified - Single Edge | 125 °C | -40 C | Black | Right Angle Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Single | Female | 3.96 mm | 0.156 in | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 34 | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | Wire Wrap | Non Specified - Dual Edge | 125 °C | -40 C | Black | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Dual | Female | 3.96 mm | 0.156 in | 2 | 2 | 17 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 34 | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Wire Wrap | Non Specified - Dual Edge | 125 °C | -40 C | Black | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Dual | Female | 3.96 mm | 0.156 in | 2 | 2 | 17 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 34 | 34 | 1 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | Wire Wrap | Non Specified - Single Edge | 125 °C | -40 C | Black | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Single | Female | 3.96 mm | 0.156 in | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 34 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | Solder | Non Specified - Dual Edge | 125 °C | -40 C | Black | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Dual | Female | 3.96 mm | 0.156 in | 2 | 2 | 17 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 34 | 0.25 Ám | 10 Áin | Solder | Non Specified - Dual Edge | 125 °C | -40 C | Black | Board Edge Straddle Mount | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Dual | Female | 3.96 mm | 0.156 in | 2 | Card Extender | 2 | 17 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 34 | 34 | 1 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | Solder | Non Specified - Single Edge | 125 °C | -40 C | Black | Through Hole | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Cantilever | Single | Female | 3.96 mm | 0.156 in |
