TJ10 Series

Catalog

TERM BLOCK PLUG 10POS STR 3.5MM

Part	Voltage - UL	Contact Material	Number of Positions	Color	Wire Strip Length [Max]	Wire Strip Length [Min]	Current - IEC	Current - UL	Type	Insulation Height	Insulation Height	Voltage - IEC	Operating Temperature [Min]	Operating Temperature [Max]	Material Flammability Rating	Contact Mating Finish	Positions Per Level	Screw Size	Wire Gauge or Range - mm²	Housing Material	Pitch [x]	Pitch [x]	Features	Mounting Type	Number of Levels	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Termination Style	Torque - Screw	Torque - Screw	Wire Gauge or Range - mm² [Min]	Wire Gauge or Range - mm² [Max]
Amphenol Anytek TJ1011820000G	300 V	Phosphor Bronze	10	Gray	7 mm	6 mm	10.5 A	10 A	Plug Female Sockets	0.437 in	11.1 mm	300 V	-40 °C	115 °C	UL94 V-0	Tin	10	M2	1.5 mm²	Thermoplastic	3.5 mm	0.138 in	Mating Flange	Free Hanging (In-Line)	1	28 AWG	16 AWG	Screw
Amphenol Anytek TJ1031020000G	300 V	Phosphor Bronze	10	Black	7 mm	6 mm	10.5 A	10 A	Plug Female Sockets	0.437 in	11.1 mm	300 V	-40 °C	115 °C	UL94 V-0	Tin	10	M2	1.5 mm²	Thermoplastic	3.81 mm	0.15 in	Mating Flange	Free Hanging (In-Line)	1	28 AWG	16 AWG	Screw
Amphenol Anytek TJ1011540000G	300 V	Phosphor Bronze	10	Green	7 mm	6 mm	10.5 A	10 A	Plug Female Sockets			300 V	-40 °C	115 °C	UL94 V-0	Tin	10	M2	1.5 mm²	Thermoplastic	3.5 mm	0.138 in	Strain Relief	Free Hanging (In-Line)	1	28 AWG	16 AWG	Screw
Amphenol Anytek TJ1051870000G	300 V	Copper	10	Gray	8 mm	7 mm		20 A	Plug Female Sockets	0.594 in	15.09 mm		-40 °C	115 °C	UL94 V-0	Tin	10	M3		Thermoplastic	5.08 mm	0.2 in	Mating Flange Retention Latches (Non-Wire Side)	Free Hanging (In-Line)	1	24 AWG	12 AWG	Screw	0.56 Nm	5 Lb-In
Amphenol Anytek TJ1071000000G	300 V	Copper	10	Black	8 mm	7 mm	20 A	20 A	Plug Female Sockets	0.594 in	15.09 mm	300 V	-40 °C	115 °C	UL94 V-0	Tin	10	M3		Thermoplastic	5 mm	0.197 in		Free Hanging (In-Line)	1	24 AWG	12 AWG	Screw	0.56 Nm	5 Lb-In	0.34 mm²	2.5 mm²
Amphenol Anytek TJ1051520000G	300 V	Copper Alloy	10	Green	8 mm	7 mm		12 A	Plug Female Sockets	0.594 in	15.09 mm		-40 °C	115 °C	UL94 V-0	Tin	10	M3		Thermoplastic Resin	5.08 mm	0.2 in	Mating Flange Retention Latches (Non-Wire Side)	Free Hanging (In-Line)	1	24 AWG	12 AWG	Screw - Rising Cage Clamp	0.56 Nm	5 Lb-In	1 mm²	2.5 mm²
Amphenol Anytek TJ1011840000G	300 V	Phosphor Bronze	10	Gray	7 mm	6 mm	10.5 A	10 A	Plug Female Sockets			300 V	-40 °C	115 °C	UL94 V-0	Tin	10	M2	1.5 mm²	Thermoplastic	3.5 mm	0.138 in	Strain Relief	Free Hanging (In-Line)	1	28 AWG	16 AWG	Screw
Amphenol Anytek TJ1011830000G	300 V	Phosphor Bronze	10	Gray	7 mm	6 mm	10.5 A	10 A	Plug Female Sockets	0.437 in	11.1 mm	300 V	-40 °C	115 °C	UL94 V-0	Tin	10	M2	1.5 mm²	Thermoplastic	3.5 mm	0.138 in		Free Hanging (In-Line)	1	28 AWG	16 AWG	Screw
Amphenol Anytek TJ1071570000G	300 V	Copper Alloy	10	Green	8 mm	7 mm		12 A	Plug Female Sockets	0.594 in	15.09 mm		-40 °C	115 °C	UL94 V-0	Tin	10	M3		Thermoplastic Resin	5 mm	0.197 in	Mating Flange Retention Latches (Non-Wire Side)	Free Hanging (In-Line)	1	24 AWG	12 AWG	Screw - Rising Cage Clamp	0.56 Nm	5 Lb-In	1 mm²	2.5 mm²
Amphenol Anytek TJ1071820000G	300 V	Copper	10	Gray	8 mm	7 mm	20 A	20 A	Plug Female Sockets	0.594 in	15.09 mm	300 V	-40 °C	115 °C	UL94 V-0	Tin	10	M3		Thermoplastic	5 mm	0.197 in	Mating Flange Retention Latches (Non-Wire Side)	Free Hanging (In-Line)	1	24 AWG	12 AWG	Screw	0.56 Nm	5 Lb-In	0.34 mm²	2.5 mm²
