MAX22258 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
IC HALF BRIDGE DRIVER 1A 14TSSOP
| Part | Voltage - Supply [Min] | Voltage - Supply [Max] | Fault Protection | Load Type | Interface | Rds On (Typ) [custom] | Rds On (Typ) [custom] | Supplier Device Package | Current - Output / Channel [custom] | Package / Case | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Voltage - Load [Max] | Voltage - Load [Min] | Current - Peak Output | Main Purpose | Voltage - Output | Utilized IC / Part | Outputs and Type | Outputs and Type | Board Type | Voltage - Input [Max] | Voltage - Input [Min] | Supplied Contents | Current - Output |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 5 V | 36 V | Over Current Over Temperature UVLO | Capacitive Inductive Resistive | Logic | 520 mOhm | 260 mOhm | 14-TSSOP-EP | 1 A | 14-TSSOP (0.173" 4.40mm Width) Exposed Pad | Surface Mount | 150 °C | -40 °C | General Purpose | 36 V | 5 V | 1 A | ||||||||||
 Analog Devices Inc./Maxim Integrated | DC/DC Converter | 24 V | MAX22258 | Isolated | 1 | Fully Populated | 36 V | 5 V | Board(s) | 200 mA |
