083612 Series
Manufacturer: Molex
Beta
⌘K
CONN MICRO-D PLUG 15POS R/A SLDR
| Part | Number of Positions | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Termination | Connector Style | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows | Material Flammability Rating | Contact Type | Connector Type | Shell Material, Finish | Contact Material | Mounting Type | Contact Finish | Features | Dielectric Material | Backset Spacing | Backset Spacing | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 15 | 0.05 | 0.05 | Solder | D-Type Micro-D | 15 µin | 0.38 µm | 125 °C | -40 °C | 2 | UL94 V-0 | Signal | Male Pins Plug | Nickel Plated Steel | Copper Alloy | Panel Mount Right Angle Through Hole | Gold | Board Lock Shielded | Liquid Crystal Polymer (LCP) | |||
 Molex | 15 | 0.05 | 0.05 | Solder | D-Type Micro-D | 15 µin | 0.38 µm | 125 °C | -55 °C | 2 | UL94 V-0 | Signal | Male Pins Plug | Nickel Plated Steel | Copper Alloy | Panel Mount Right Angle Through Hole | Gold | Board Lock Shielded | Liquid Crystal Polymer (LCP) | 0.269 in | 6.85 mm | Housing/Shell (Unthreaded) |
 Molex | 15 | 0.05 | 0.043 | Solder | D-Type Micro-D | 15 µin | 0.38 µm | 125 °C | -40 °C | 2 | UL94 V-0 | Signal | Male Pins Plug | Nickel Plated Steel | Copper Alloy | Through Hole | Gold | Board Lock Shielded | Liquid Crystal Polymer (LCP) | Female Screwlock (2-56) Mating Side |
