305-044 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 44POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Number of Positions/Bay/Row | Gender | Pitch | Pitch | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Color | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Card Type | Contact Material | Mounting Type | Number of Rows [custom] | Number of Positions | Termination | Contact Type | Read Out | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | 22 | Female | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Green | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Non Specified - Dual Edge | Copper Alloy | Panel Mount Through Hole | 2 | 44 | Solder | Semi Bellows | Dual | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 22 | Female | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Green | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Non Specified - Dual Edge | Copper Alloy | Panel Mount | 2 | 44 | Solder Eyelet(s) | Semi Bellows | Dual | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 22 | Female | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Green | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Non Specified - Dual Edge | Copper Alloy | Panel Mount | 2 | 44 | Solder Eyelet(s) | Semi Bellows | Dual | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 22 | Female | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Green | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Non Specified - Dual Edge | Copper Alloy | Panel Mount Through Hole | 2 | 44 | Solder | Semi Bellows | Dual | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 22 | Female | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Green | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Dual Edge | Copper Alloy | Board Edge Straddle Mount | 2 | 44 | Solder | Semi Bellows | Dual | Card Extender | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 22 | Female | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Green | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | Copper Alloy | Board Edge Straddle Mount | 2 | 44 | Solder | Semi Bellows | Dual | Card Extender Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | 22 | Female | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Green | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Non Specified - Dual Edge | Copper Alloy | Panel Mount | 2 | 44 | Solder Eyelet(s) | Semi Bellows | Dual | |
 EDAC Inc. | Polyester Thermoplastic | 2 | 22 | Female | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Green | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Dual Edge | Copper Alloy | Panel Mount Through Hole | 2 | 44 | Solder | Semi Bellows | Dual | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 22 | Female | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Green | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Dual Edge | Copper Alloy | Panel Mount Through Hole | 2 | 44 | Solder | Semi Bellows | Dual | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 22 | Female | 3.96 mm | 0.156 in | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Green | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | Copper Alloy | Panel Mount Through Hole | 2 | 44 | Solder | Semi Bellows | Dual |
