8303 Series

Catalog

MULTI-PAIR 6COND 22AWG

Part	Shield Coverage	Shield Material	Cable Type	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length	Length	Conductor Strand [custom]	Conductor Strand [custom]	Shield Type	Number of Conductors	Usage	Voltage	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket Color	Operating Temperature [Max]	Operating Temperature [Min]	Wire Gauge	Conductor Material	Ratings	Conductor Insulation	Length [x]	Length [x]
Belden Inc. 8303 0601000	65 % 100 %	Aluminum Copper Tinned	Multi-Pair	Poly-Vinyl Chloride (PVC)	0.294 in	7.47 mm	304.8 m	1000 ft	30 AWG	7	Braid Foil	6	Computer	300 VDC	0.035 in	0.889 mm	Chrome	80 °C	-30 ░C	22 AWG	Copper Tinned	UL Style 2464	Poly-Vinyl Chloride (PVC)
Belden Inc. 8303 060100	65 % 100 %	Aluminum Copper Tinned	Multi-Pair	Poly-Vinyl Chloride (PVC)	0.294 in	7.47 mm			30 AWG	7	Braid Foil	6	Computer		0.035 in	0.889 mm	Chrome	80 °C	-30 ░C	22 AWG	Copper Tinned	UL Style 2464	Poly-Vinyl Chloride (PVC)	100 ft	30.5 m
Belden Inc. 8303 0605000	65 % 100 %	Aluminum Copper Tinned	Multi-Pair	Poly-Vinyl Chloride (PVC)	0.294 in	7.47 mm			30 AWG	7	Braid Foil	6	Computer	300 VDC	0.035 in	0.889 mm	Chrome	80 °C	-30 ░C	22 AWG	Copper Tinned	UL Style 2464	Poly-Vinyl Chloride (PVC)
Belden Inc. 8303 060500	65 % 100 %	Aluminum Copper Tinned	Multi-Pair	Poly-Vinyl Chloride (PVC)	0.294 in	7.47 mm	152.4 m	500 ft	30 AWG	7	Braid Foil	6	Computer	300 VDC	0.035 in	0.889 mm	Chrome	80 °C	-30 ░C	22 AWG	Copper Tinned	UL Style 2464	Poly-Vinyl Chloride (PVC)
