R31758 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SHV F STR BHDP
| Part | Body Material | Operating Temperature [Min] | Operating Temperature [Max] | Center Contact Plating | Dielectric Material | Mating Cycles | Includes | Body Finish | Mounting Type | Frequency - Max [Max] | Connector Type | Mounting Feature | Connector Style | Contact Termination | Center Contact Material | Fastening Type | Housing Color | Features | Impedance | Number of Ports | Shield Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Brass | -65 ░C | 125 °C | Gold | Polytetrafluoroethylene (PTFE) | 500 | 1 Connector 1 Lockwasher 1 Nut | Nickel | Panel Mount | 2 GHz | Receptacle Female Socket | Bulkhead - Rear Side Nut | SHV | Solder Cup | Brass | Bayonet Lock | Silver | Extended Insulation | 50 Ohms | 1 | Solder |
