Temp-Flex High-Performance Flat-Ribbon Cable, 4 Circuits, 1.27mm Pitch, 28 AWG, Silver Plated Copper, UL 20424, 7/36 Stranded Extruded FEP, Blue with Blue Polarity Stripe
Temp-Flex High-Performance Flat-Ribbon Cable, 4 Circuits, 1.27mm Pitch, 28 AWG, Silver Plated Copper, UL 20424, 7/36 Stranded Extruded FEP, Blue with Blue Polarity Stripe
Temp-Flex High-Performance Flat-Ribbon Cable, 4 Circuits, 1.27mm Pitch, 28 AWG, Silver Plated Copper, UL 20424, 7/36 Stranded Extruded FEP, Blue with Blue Polarity Stripe
| Part | Voltage | Pitch [x] | Pitch [x] | Shielding | Jacket (Insulation) Material | Jacket Color | Conductor Material | Ribbon Width [y] | Ribbon Width [y] | Cable Type | Length | Length | Wire Gauge | Conductor Strand [custom] | Conductor Strand [custom] | Number of Conductors | Operating Temperature | Length [x] | Length [x] | Ribbon Width [custom] | Ribbon Width [custom] | Ratings | Operating Temperature [Min] | Operating Temperature [Max] | First Conductor Mark | Conductor Strand [custom] | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | 300 V | 0.05 in | 1.27 mm | Unshielded | Fluorinated Ethylene-Propylene (FEP) | Blue | Copper Alloy Silver Coated | 1.7 in | 43.18 mm | Flat Cable | 50 yds | 45.72 m | 28 AWG | 19 Strands | 40 AWG | 34 | 200 °C | ||||||||||
Molex | 0.05 in | 1.27 mm | Unshielded | Blue | Copper Silver Coated | Flat Cable | 28 AWG | 19 Strands | 40 AWG | 37 | 100 ft | 30.48 m | |||||||||||||||
Molex | 0.017 in | 0.43 mm | Unshielded | Natural | Flat Cable | 32 AWG | 10 | ||||||||||||||||||||
 Molex | 300 V | 0.05 in | 1.27 mm | Unshielded | Fluorinated Ethylene-Propylene (FEP) | Blue | Copper Silver Coated | Flat Cable | 28 AWG | 7 | 36 AWG | 10 | 100 ft | 30.48 m | 0.5 " | 12.7 mm | UL Style 20424 | -55 °C | 200 °C | ||||||||
Molex | 300 V | 0.05 in | 1.27 mm | Unshielded | Fluorinated Ethylene-Propylene (FEP) | Blue | Copper Silver Coated | Flat Cable | 28 AWG | 7 | 36 AWG | 10 | 200 °C | 100 ft | 30.48 m | 0.5 " | 12.7 mm | Red | |||||||||
Molex | 300 V | 0.05 in | 1.27 mm | Unshielded | Fluorinated Ethylene-Propylene (FEP) | Blue | Copper Silver Coated | 1.2 in | 30.48 mm | Flat Cable | 28 AWG | 7 | 36 AWG | 24 | 100 ft | 30.48 m | UL Style 20424 | -65 ░C | 200 °C | ||||||||
Molex | 150 V | 0.025 in | 0.64 mm | Unshielded | Fluorinated Ethylene-Propylene (FEP) | Natural | Copper Silver Coated | Flat Cable | 30 AWG | 7 | 4 | 100 ft | 30.48 m | UL Style 20726 | -55 °C | 200 °C | Blue | 38 AWG | |||||||||
Molex | 0.05 in | 1.27 mm | Unshielded | Natural | Copper Silver Coated | Flat Cable | 28 AWG | 19 Strands | 40 AWG | 5 | 100 ft | 30.48 m | |||||||||||||||
Molex | 0.05 in | 1.27 mm | Unshielded | Fluorinated Ethylene-Propylene (FEP) | Natural | Copper Silver Coated | Flat Cable | 24 AWG | 19 Strands | 28 | 100 ft | 30.48 m | 36 AWG | ||||||||||||||
 Molex | 300 V | 0.05 in | 1.27 mm | Unshielded | Fluorinated Ethylene-Propylene (FEP) | Natural | Copper Alloy Silver Coated | Flat Cable | 28 AWG | 19 Strands | 40 AWG | 9 | 200 °C | UL Style 20424 | Enter Number of Feet in Order Quantity |
