TR9CA3600 Series
Manufacturer: GlobTek, Inc.
Beta
⌘K
AC/DC DESKTOP ADAPTER 5V 18W
| Part | Input Connector | Operating Temperature [Min] | Operating Temperature [Max] | Form | Cord Length | Cord Length | Voltage - Output | Voltage - Input [Max] | Voltage - Input [Min] | Output Connector | Approval Agency | Input Type | Applications | Current - Output (Max) [Max] | Efficiency | Standard Number | Region Utilized | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | No Load Power Consumption | Power (Watts) | Size / Dimension [y] | Size / Dimension [z] | Cord Length | Polarization | Output Connector [diameter] | Output Connector [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 GlobTek, Inc. | IEC 320-C14 | -20 ░C | 40 °C | Desktop (Class I) | 1 m | 39.4 in | 5 V | 264 VAC | 90 VAC | USB A Receptacle | BSMI CB CCC CE cETLus cULus EAC ETL FCC LPS NOM PSE RCM S-Mark UkrSEPRO UL VCCI | Cord (Sold Separately) | Household Appliances ITE (Commercial) Medical | 3.6 A | CoC Tier 1 Level VI | 60335-1 60601-1 60950-1 62368-1 | International | 3.43 " | 1.83 in | 32 mm | 1.26 " | 46.5 mm | 87 mm | 75 mW | 18 W | ||||||
 GlobTek, Inc. | IEC 320-C14 | -20 ░C | 40 °C | Desktop (Class I) | 1.2 m | 5 V | 264 VAC | 90 VAC | Barrel Plug Kit (1.3mm x 3.5mm | BSMI CB CCC CE cETLus cULus EAC ETL FCC LPS NOM PSE RCM S-Mark UkrSEPRO UL VCCI | Cord (Sold Separately) | Household Appliances ITE (Commercial) Medical | 3.6 A | Level VI | 1310 60335-1 60601-1-11 60601-1-2 60950-1 62368-1 | International | 3.43 " | 1.85 in | 1.26 " | 87 mm | 75 mW | 18 W | 47 mm | 32 mm | 47.2 in | ||||||
 GlobTek, Inc. | IEC 320-C14 | -20 ░C | 40 °C | Desktop (Class I) | 1.2 m | 5 V | 264 VAC | 90 VAC | USB C | BSMI CB CCC CE cETLus cULus EAC ETL FCC LPS NOM PSE RCM S-Mark UkrSEPRO UL VCCI | Cord (Sold Separately) | Household Appliances ITE (Commercial) Medical | 3.6 A | Level VI | 1310 60335-1 60601-1-11 60601-1-2 60950-1 62368-1 | International | 3.43 " | 1.85 in | 1.26 " | 87 mm | 75 mW | 18 W | 47 mm | 32 mm | 47.2 in | ||||||
 GlobTek, Inc. | IEC 320-C14 | -20 ░C | 40 °C | Desktop (Class I) | 1.2 m | 5 V | 264 VAC | 90 VAC | Barrel Plug | BSMI CB CCC CE cETLus cULus EAC ETL FCC LPS NOM PSE RCM S-Mark UkrSEPRO UL VCCI | Cord (Sold Separately) | Household Appliances ITE (Commercial) Medical | 3.6 A | Level VI | 1310 60335-1 60601-1-11 60601-1-2 60950-1 62368-1 | International | 3.43 " | 1.85 in | 1.26 " | 87 mm | 75 mW | 18 W | 47 mm | 32 mm | 47.2 in | Positive Center | 2.5 mm 5.5 mm | 11 mm |
