LDD Comm X7R Series

Manufacturer: KEMET

Catalog

MULTILAYER CERAMIC CAPACITORS MLCC - LEADED 50V 1UF X7R 20% LS=5.08MM

Part	Lead Style	Mounting Type	Height - Seated (Max) [Max]	Height - Seated (Max)	Lead Spacing	Lead Spacing	Capacitance	Applications	Voltage - Rated	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Operating Temperature [Min]	Operating Temperature [Max]	Temperature Coefficient	Package / Case	Tolerance	Size / Dimension [custom]	Size / Dimension [diameter]	Size / Dimension [diameter]	Size / Dimension [custom]
KEMET C062C105M5R5CA	Straight	Through Hole	0.3 in	7.62 mm	0.2 in	5.08 mm	1 µF	Bypass Decoupling	50 VDC	0.29 "	2.29 mm	7.37 mm	0.09 "	-55 C	125 °C	X7R	Radial	20 %
KEMET C052C470J2R5TA7301	Formed Leads	Through Hole	0.245 "	6.22 mm	0.2 in	5.08 mm	47 pF	Bypass Decoupling	200 VDC	0.19 "	2.29 mm	4.83 mm	0.09 "	-55 C	125 °C	X7R	Radial	5 %
KEMET C052C332K1R5CA
KEMET C052C101K2R5CA	Formed Leads	Through Hole	0.245 "	6.22 mm	0.2 in	5.08 mm	100 pF	Bypass Decoupling	200 VDC	0.19 "	2.29 mm	4.83 mm	0.09 "	-55 C	125 °C	X7R	Radial	10 %
KEMET C052C222K1R5CA	Formed Leads	Through Hole	0.245 "	6.22 mm	0.2 in	5.08 mm	2200 pF	Bypass Decoupling	100 V	0.19 "	2.29 mm	4.83 mm	0.09 "	-55 C	125 °C	X7R	Radial	10 %
KEMET C052C331K2R5CA	Formed Leads	Through Hole	0.245 "	6.22 mm	0.2 in	5.08 mm	330 pF	Bypass Decoupling	200 VDC	0.19 "	2.29 mm	4.83 mm	0.09 "	-55 C	125 °C	X7R	Radial	10 %
KEMET C052C472K1R5TA	Formed Leads	Through Hole	0.245 "	6.22 mm	0.2 in	5.08 mm	0.0047 µF	Bypass Decoupling	100 V	0.19 "	2.29 mm	4.83 mm	0.09 "	-55 C	125 °C	X7R	Radial	10 %
KEMET C202C224K1R5CA	Straight	Through Hole					0.22 µF	Bypass Decoupling	100 V					-55 C	125 °C	X7R	Axial	10 %
KEMET C114C103M1R5CA	Straight	Through Hole					10000 pF	Bypass Decoupling	100 V					-55 C	125 °C	X7R	Axial	20 %	0.16 "	0.09 in	2.29 mm	4.06 mm
KEMET C062C684K5R5TA	Straight	Through Hole	0.3 in	7.62 mm	0.2 in	5.08 mm	0.68 µF	Bypass Decoupling	50 VDC	0.29 "	2.29 mm	7.37 mm	0.09 "	-55 C	125 °C	X7R	Radial	10 %
