ACPL-C87 Series

Catalog

IC OPAMP ISOLATION 1 CIRC 8SO

Part	Amplifier Type	Voltage - Supply Span (Min) [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Supply Span (Max) [Max]	-3db Bandwidth	Mounting Type	Current - Output / Channel	Voltage - Input Offset	Package / Case	Package / Case	Current - Input Bias	Output Type	Number of Circuits	Current - Supply	Supplier Device Package
Broadcom Limited ACPL-C87B-500E	Isolation	3 V	-40 C	105 ░C	5.5 V	100 kHz	Surface Mount	30 mA	300 çV	0.268 in 6.81 mm	8-SOIC	1.5 nA	Differential	1	10.5 mA	8-SO Stretched
Broadcom Limited ACPL-C87B-000E	Isolation	3 V	-40 C	105 ░C	5.5 V	100 kHz	Surface Mount	30 mA	300 çV	0.268 in 6.81 mm	8-SOIC	1.5 nA	Differential	1	10.5 mA	8-SO Stretched
Broadcom Limited ACPL-C87AT-000E	Isolation	3 V	-40 C	125 °C	5.5 V	100 kHz	Surface Mount	30 mA	300 çV	0.268 in 6.81 mm	8-SOIC	1 nA		1	10.5 mA	8-SO Stretched
Broadcom Limited ACPL-C87BT-500E	Isolation	3 V	-40 C	125 °C	5.5 V	100 kHz	Surface Mount	30 mA	300 çV	0.268 in 6.81 mm	8-SOIC	1 nA	Differential	1	10.5 mA	8-SO Stretched
Broadcom Limited ACPL-C87A-000E	Isolation	3 V	-40 C	105 ░C	5.5 V	100 kHz	Surface Mount	30 mA	300 çV	0.268 in 6.81 mm	8-SOIC	1.5 nA	Differential	1	10.5 mA	8-SO
