628-009 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D SUB RCPT 9POS VERT METAL
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Color | Shell Material, Finish | Material Flammability Rating | Current Rating (Amps) | Contact Type | Features | Number of Positions | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Connector Style | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Connector Type | Number of Rows [custom] | Flange Feature | Contact Finish | Termination | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Brass | Black | Nickel Plated Steel | UL94 V-0 | 3 A | Signal and Power | Shielded | 9 | 1 | DE E | D-Sub | Free Hanging (In-Line) | 0.38 µm | 15 µin | Receptacle Female Sockets | 2 | Board Side (4-40) | Gold | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Brass | Black | UL94 V-0 | 3 A | Signal and Power | Board Lock Shielded | 9 | 1 | DE E | D-Sub | Through Hole | 0.38 µm | 15 µin | Receptacle Female Sockets | 2 | Board Side (4-40) | Gold | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Brass | Black | UL94 V-0 | 3 A | Signal and Power | Board Lock Shielded | 9 | 1 | DE E | D-Sub | Through Hole | 0.76 Ám | 30 Áin | Receptacle Female Sockets | 2 | Board Side (4-40) | Gold | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Brass | Black | UL94 V-0 | 3 A | Signal and Power | Shielded | 9 | 1 | DE E | D-Sub | Through Hole | Receptacle Female Sockets | 2 | Board Side (4-40) | Gold | Solder | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Brass | Black | Nickel Plated Steel | UL94 V-0 | 3 A | Signal and Power | Board Lock Shielded | 9 | 1 | DE E | D-Sub | Through Hole | 0.38 µm | 15 µin | Receptacle Female Sockets | 2 | Board Side (4-40) | Gold | Solder | |
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Brass | Black | Nickel Plated Steel | UL94 V-0 | 3 A | Signal and Power | Shielded | 9 | 1 | DE E | D-Sub | Through Hole | Receptacle Female Sockets | 2 | Board Side (4-40) | Gold | Solder | Flash | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Brass | Black | Nickel Plated Steel | UL94 V-0 | 3 A | Signal and Power | Board Lock Shielded | 9 | 1 | DE E | D-Sub | Through Hole | 0.38 µm | 15 µin | Receptacle Female Sockets | 2 | Board Side (4-40) | Gold | Solder | |
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Brass | Black | Nickel Plated Steel | UL94 V-0 | 3 A | Signal and Power | Board Lock Shielded | 9 | 1 | DE E | D-Sub | Through Hole | Receptacle Female Sockets | 2 | Board Side (4-40) | Gold | Solder | Flash | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Brass | Black | UL94 V-0 | 3 A | Signal and Power | Shielded | 9 | 1 | DE E | D-Sub | Through Hole | Receptacle Female Sockets | 2 | Board Side (4-40) | Gold | Solder | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Brass | Black | Nickel Plated Steel | UL94 V-0 | 3 A | Signal and Power | Shielded | 9 | 1 | DE E | D-Sub | Free Hanging (In-Line) | 0.38 µm | 15 µin | Receptacle Female Sockets | 2 | Board Side (4-40) | Gold |
