2301841 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
D SUB CONNECTOR, STANDARD, RECEPTACLE, AMPLIMITE HD-20 SERIES, 25 CONTACTS, DB, SOLDER
| Part | Dielectric Material | Number of Rows | Material Flammability Rating | Connector Style | Connector Type | Mounting Type | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Termination | Voltage Rating | Current Rating (Amps) | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature | Shell Material, Finish | Contact Finish | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Polybutylene Terephthalate (PBT) Glass Filled | 2 | UL94 V-0 | D-Sub | Receptacle Female Sockets | Through Hole | B DB | 3 | Solder | 250 VDC | 1.5 A | Brass | 105 ░C | -55 °C | Female Screwlock (4-40) Mating Side | Steel Tin-Nickel Plated | Gold | Signal | 15 µin | 0.38 µm | Black |
