PTN780 Series

Catalog

DC DC CONVERTER 2.5-12.6V

Part	Voltage - Input (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Features	Number of Outputs	Type	Mounting Type	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Voltage - Output 1 [Max]	Voltage - Output 1 [Min]	Efficiency	Voltage - Input (Min) [Min]	Applications	Package / Case	Current - Output (Max) [Max]
Texas Instruments PTN78020WAST	36 V	85 °C	-40 °C	OCP OTP Remote On/Off UVLO	1	Non-Isolated PoL Module	Surface Mount	1.5 in	22.1 mm	38.1 mm	9.7 mm	0.87 in	0.38 in	12.6 V	2.5 V	94 %	7 V	ITE (Commercial)	7-SMD Module	6 A
Texas Instruments PTN78000HAST	36 V	85 °C	-40 °C	OCP OTP UVLO	1	Non-Isolated PoL Module	Surface Mount	0.75 in	12.7 mm	19.1 mm	9.1 mm	0.5 in	0.36 in	22 V	11.85 V	94 %	15 V	ITE (Commercial)	5-SMD Module	1.5 A
Texas Instruments PTN78000HAZT	36 V	85 °C	-40 °C	OCP OTP UVLO	1	Non-Isolated PoL Module	Surface Mount	0.75 in	12.7 mm	19.1 mm	9.1 mm	0.5 in	0.36 in	22 V	11.85 V	94 %	15 V	ITE (Commercial)	5-SMD Module	1.5 A
Texas Instruments PTN78020HAZT	36 V	85 °C	-40 °C	OCP OTP Remote On/Off UVLO	1	Non-Isolated PoL Module	Surface Mount	1.5 in	22.1 mm	38.1 mm	9.7 mm	0.87 in	0.38 in	22 V	11.85 V	96 %	15 V	ITE (Commercial)	7-SMD Module	6 A
Texas Instruments PTN78060HAST	36 V	85 °C	-40 °C	OCP OTP Remote On/Off UVLO	1	Non-Isolated PoL Module	Surface Mount	1 in	15.7 mm	25.4 mm	9.7 mm	0.62 "	0.38 in	22 V	11.85 V	96 %	15 V	ITE (Commercial)	7-SMD Module	3 A
