833-039 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 39POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Positions/Bay/Row | Flange Feature | Termination | Contact Type | Pitch | Pitch | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Gender | Color | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Read Out | Number of Rows | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 39 | 4-40 Threaded Insert Top Mount Opening | Solder | Cantilever | 3.96 mm | 0.156 in | 39 | 0.25 Ám | 10 Áin | Through Hole | Female | Green | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Single | 1 | Gold | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 39 | M3 Threaded Insert Top Mount Opening | Solder | Cantilever | 3.96 mm | 0.156 in | 39 | 0.25 Ám | 10 Áin | Through Hole | Female | Green | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Single | 1 | Gold | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 39 | M3 Threaded Insert Top Mount Opening | Solder | Cantilever | 3.96 mm | 0.156 in | 39 | 0.25 Ám | 10 Áin | Through Hole | Female | Green | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Single | 1 | Gold | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 39 | Solder | Cantilever | 3.96 mm | 0.156 in | 39 | 0.25 Ám | 10 Áin | Through Hole | Female | Green | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Single | 1 | Gold | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 39 | Flush Mount Top Opening Unthreaded | Wire Wrap | Cantilever | 3.96 mm | 0.156 in | 39 | 0.25 Ám | 10 Áin | Through Hole | Female | Green | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Single | 1 | Gold | 3.25 mm | 0.128 " |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 39 | Solder | Cantilever | 3.96 mm | 0.156 in | 39 | 0.25 Ám | 10 Áin | Through Hole | Female | Green | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Single | 1 | Gold | 3.25 mm | 0.128 " | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 39 | Solder | Cantilever | 3.96 mm | 0.156 in | 39 | 0.25 Ám | 10 Áin | Through Hole | Female | Green | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Single | 1 | Gold | 3.25 mm | 0.128 " | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 39 | Side Mount Opening Unthreaded | Solder | Cantilever | 3.96 mm | 0.156 in | 39 | 0.25 Ám | 10 Áin | Right Angle Through Hole | Female | Green | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Single | 1 | Gold | 3.25 mm | 0.128 " |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 39 | Solder | Cantilever | 3.96 mm | 0.156 in | 39 | 0.25 Ám | 10 Áin | Right Angle Through Hole | Female | Green | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Single | 1 | Gold | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 39 | M3 Threaded Insert Top Mount Opening | Wire Wrap | Cantilever | 3.96 mm | 0.156 in | 39 | 0.25 Ám | 10 Áin | Through Hole | Female | Green | 125 °C | -40 C | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Single | 1 | Gold |
