637-026 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB HD PLUG 26P SLDR CUP
| Part | Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Dielectric Material | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Number of Positions | Material Flammability Rating | Number of Rows [custom] | Features | Flange Feature | Flange Feature | Current Rating (Amps) | Connector Type | Contact Type | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout | Connector Style | Shell Material, Finish | Contact Finish | Termination | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | -55 C | 125 °C | Brass | Polyester Thermoplastic | 30 Áin | 0.76 Ám | Free Hanging (In-Line) | 26 | UL94 V-0 | 3 | Board Lock Grounding Indents Shielded | Housing/Shell | 4-40 | 3 A | Plug Male Pins | Signal | 2 | DA A | D-Sub High Density | Nickel Plated Steel | Gold | ||
 EDAC Inc. | Black | -55 C | 125 °C | Brass | Polyester Thermoplastic | 15 µin | 0.38 µm | Panel Mount Through Hole | 26 | UL94 V-0 | 3 | Grounding Indents Shielded | Board Side (4-40) | 3 A | Plug Male Pins | Signal | 2 | DA A | D-Sub High Density | Nickel Plated Steel | Gold | Solder | ||
 EDAC Inc. | Black | -55 C | 125 °C | Brass | Polyester Thermoplastic | 15 µin | 0.38 µm | Panel Mount Through Hole | 26 | UL94 V-0 | 3 | Grounding Indents Shielded | Board Side (4-40) | 3 A | Plug Male Pins | Signal | 2 | DA A | D-Sub High Density | Gold | Solder | |||
 EDAC Inc. | Black | -55 C | 85 °C | Brass | Polyester Thermoplastic | Free Hanging (In-Line) | 26 | UL94 V-0 | 3 | Grounding Indents Shielded | Housing/Shell (Unthreaded) | 3 A | Plug Male Pins | Signal | 2 | DA A | D-Sub High Density | Gold | Flash | |||||
 EDAC Inc. | Black | -55 C | 125 °C | Brass | Polyester Thermoplastic | Panel Mount Through Hole | 26 | UL94 V-0 | 3 | Board Lock Grounding Indents Shielded | Housing/Shell | 4-40 | 3 A | Plug Male Pins | Signal | 2 | DA A | D-Sub High Density | Gold | Solder | Flash | |||
 EDAC Inc. | Black | -55 C | 85 °C | Brass | Polyester Thermoplastic | 30 Áin | 0.76 Ám | Panel Mount Through Hole | 26 | UL94 V-0 | 3 | Board Lock Grounding Indents Shielded | 4-40 | 3 A | Plug Male Pins | Signal | 2 | DA A | D-Sub High Density | Gold | Solder | |||
 EDAC Inc. | Black | -55 C | 85 °C | Brass | Polyester Thermoplastic | 15 µin | 0.38 µm | Free Hanging (In-Line) | 26 | UL94 V-0 | 3 | Board Lock Grounding Indents Shielded | Housing/Shell | 4-40 | 3 A | Plug Male Pins | Signal | 2 | DA A | D-Sub High Density | Gold | |||
 EDAC Inc. | Black | -55 C | 85 °C | Brass | Polyester Thermoplastic | Panel Mount Through Hole | 26 | UL94 V-0 | 3 | Grounding Indents Shielded | Housing/Shell | 4-40 | 3 A | Plug Male Pins | Signal | 2 | DA A | D-Sub High Density | Nickel Plated Steel | Gold | Solder | Flash | ||
 EDAC Inc. | Black | -55 C | 125 °C | Brass | Polyester Thermoplastic | 30 Áin | 0.76 Ám | Panel Mount Through Hole | 26 | UL94 V-0 | 3 | Grounding Indents Shielded | 4-40 | 3 A | Plug Male Pins | Signal | 2 | DA A | D-Sub High Density | Gold | Solder | |||
 EDAC Inc. | Black | -55 C | 125 °C | Brass | Polyester Thermoplastic | 30 Áin | 0.76 Ám | Panel Mount Through Hole | 26 | UL94 V-0 | 3 | Grounding Indents Shielded | Housing/Shell (Unthreaded) | 3 A | Plug Male Pins | Signal | 2 | DA A | D-Sub High Density | Nickel Plated Steel | Gold | Solder |
