807-039 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 78POS 0.156
...
| Part | Number of Positions/Bay/Row [custom] | Gender | Mounting Type | Termination Rows | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Card Type | Flange Feature | Number of Rows | Color | Pitch [x] | Pitch [x] | Contact Material | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Number of Positions | Read Out | Material - Insulation | Termination | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 39 | Female | Through Hole Right Angle | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | 2 | Green | 0.156 in | 3.96 mm | Copper Alloy | Tin | 125 °C | -40 °C | Semi Bellows | 78 | Dual | Diallyl Phthalate (DAP) | Solder | ||||
 EDAC Inc. | 39 | Female | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | 1 | Green | 0.156 in | 3.96 mm | Copper Alloy | Gold | 125 °C | -40 °C | Semi Bellows | 39 | Single | Diallyl Phthalate (DAP) | Solder | 10 Áin | 0.25 Ám | ||
 EDAC Inc. | 39 | Female | Through Hole Right Angle | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | 1 | Green | 0.156 in | 3.96 mm | Copper Alloy | Gold | 125 °C | -40 °C | Semi Bellows | 39 | Single | Diallyl Phthalate (DAP) | Solder | 10 Áin | 0.25 Ám | 3.25 mm | 0.128 " |
 EDAC Inc. | 39 | Female | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Green | 0.156 in | 3.96 mm | Copper Alloy | Gold | 125 °C | -40 °C | Semi Bellows | 78 | Dual | Diallyl Phthalate (DAP) | Wire Wrap | 10 Áin | 0.25 Ám | ||
 EDAC Inc. | 39 | Female | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | 2 | Green | 0.156 in | 3.96 mm | Copper Alloy | Gold | 125 °C | -40 °C | Semi Bellows | 78 | Dual | Diallyl Phthalate (DAP) | Solder | 10 Áin | 0.25 Ám | ||
 EDAC Inc. | 39 | Female | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | 2 | Green | 0.156 in | 3.96 mm | Copper Alloy | Tin | 125 °C | -40 °C | Semi Bellows | 78 | Dual | Diallyl Phthalate (DAP) | Wire Wrap | ||||
 EDAC Inc. | 39 | Female | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | 1 | Green | 0.156 in | 3.96 mm | Copper Alloy | Gold | 125 °C | -40 °C | Semi Bellows | 39 | Single | Diallyl Phthalate (DAP) | Solder Eyelet(s) | 10 Áin | 0.25 Ám | 3.96 mm | 0.156 in |
 EDAC Inc. | 39 | Female | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | 1 | Green | 0.156 in | 3.96 mm | Copper Alloy | Gold | 125 °C | -40 °C | Semi Bellows | 39 | Single | Diallyl Phthalate (DAP) | Solder Eyelet(s) | 10 Áin | 0.25 Ám | 3.25 mm | 0.128 " |
 EDAC Inc. | 39 | Female | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | 2 | Green | 0.156 in | 3.96 mm | Copper Alloy | Tin | 125 °C | -40 °C | Semi Bellows | 78 | Dual | Diallyl Phthalate (DAP) | Solder Eyelet(s) | |||||
 EDAC Inc. | 39 | Female | Through Hole | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Single Edge | Flush Mount M3 Threaded Insert Top Opening | 1 | Green | 0.156 in | 3.96 mm | Copper Alloy | Gold | 125 °C | -40 °C | Semi Bellows | 39 | Single | Diallyl Phthalate (DAP) | Solder | 10 Áin | 0.25 Ám |
